OIL PUMP

GP100U 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

Oil pump diagram GP100U 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

OIL PUMP GP100U 1978 (C) (E01 E02 E06 E13 E14 E24 E30)
OIL PUMP GP100U 1978 (C) (E01 E02 E06 E13 E14 E24 E30)
OIL PUMP GP100U 1978 (C) (E01 E02 E06 E13 E14 E24 E30)
prices are in EUR
ref
part #
description
quantity
1
1610039110
ref: 1
PUMP ASSY, OIL
1610039110
€ 202.50
2-2
1673103101
ref: 2-2
GASKET,OIL PUMP (NAS)
1673103101
€ 2.50
3
0211205168
ref: 3
SCREW
0211205168
€ 2.50
4
0211205308
ref: 4
SCREW
0211205308
€ 1.50
5
0832121058
ref: 5
LOCK WASHER
0832121058
€ 2.00
6
1632139100
ref: 6
GEAR,OIL PUMP DRIVE
1632139100
€ 14.00
7
1632239100
ref: 7
SHAFT,OIL PUMP DRIVE GEAR
€ 13.50
8
0926102001
ref: 8
PIN(2.5X19.8)
0926102001
€ 1.50
9
1629203111
ref: 9
TERMINAL,CABLE
1629203111
€ 3.50
10
0911908014
ref: 10
BOLT
0911908014
€ 3.50
11
0831012088
ref: 11
NUT
0831012088
€ 2.00
12
1138539100
ref: 12
CAP,OIL PUMP INSPECTION
1138539100
€ 5.50
13
0211206108
ref: 13
SCREW
0211206108
€ 1.50
14
1681039100
ref: 14
HOSE,OIL NO.1
€ 17.50
15
0936006003
ref: 15
UNION BOLT
0936006003
€ 5.00
16
0916806004
ref: 16
GASKET(6.2X11X1).2 (NAS)
0916806004
€ 1.50
17
0930808001
ref: 17
GROMMET
0930808001
€ 2.00
18
0940108401
ref: 18
CLIP
0940108401
€ 1.50
19
1682039100
ref: 19
HOSE,OIL NO.2
1682039100
€ 6.00
20
1683139100
ref: 20
GROMMET,OIL HOSE NO.3
€ 4.00
21
0940104401
ref: 21
CLIP
0940104401
€ 2.50
