REAR MASTER CYLINDER
GS550EF 1985 (F) USA (E03)
Rear master cylinder diagram GS550EF 1985 (F) USA (E03)
REAR MASTER CYLINDER GS550EF 1985 (F) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6960043400
ref: 1
69600-43401
CYLINDER ASSEMBLY,REAR MASTER
€ 201.00
2
6960034810
ref: 2
PISTON/CUP SET
€ 36.50
3
6969234300
ref: 3
YOKE
€ 11.00
4
6967031301
ref: 4
ROD,PUSH
€ 15.00
5
6969334300
ref: 5
69693-05A00
NUT,MASTER CYLINDER
€ 1.50
6
6969145001
ref: 6
BOOT
€ 6.50
7
5116270040
ref: 7
CIRCLIP
€ 3.00
8
0151708255
ref: 8
01550-0825A
BOLT
€ 2.50
9
6974034230
ref: 9
69740-31D00
TANK ASSEMBLY,RESERVOIR
€ 27.50
10
5966933603
ref: 10
59669-07D00
CAP
€ 16.50
11
5966818441
ref: 11
PLATE,DIAPHRAGM
€ 3.50
12
5966718441
ref: 12
DIAPHRAGM
€ 8.50
13
0110706168
ref: 13
01500-06167
BOLT, UPPER
€ 3.00
14
0832121067
ref: 14
08321-01067
WASHER,LOCK
€ 2.50
15
0832221067
ref: 15
08322-01067
WASHER
€ 2.00
16
6973143401
ref: 16
HOSE,RESERVOIR TANK
€ 13.00
17
0940016302
ref: 17
09400-16304
CLAMP
€ 4.50
18
6948043403
ref: 18
HOSE,REAR BRAKE
€ 72.00
19
0916110009
ref: 19
WASHER(10X15X1.5)
€ 2.00
20
0936010017
ref: 20
BOLT UNION
€ 6.50
