FRANE COVER (GS750B
GS750N 1979 (N) USA (E03)
Frane cover (gs750b diagram GS750N 1979 (N) USA (E03)
FRANE COVER (GS750B GS750N 1979 (N) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
4711145000291
ref: 1-1
47111-45000
COVER,FRAME,RIGHT
€ 71.00
1-2
471114500005T
ref: 1-2
47111-45000
COVER,FRAME,RIGHT
€ 71.00
1-3
471114500005N
ref: 1-3
47111-45000
COVER,FRAME,RIGHT
€ 71.00
1-4
4711145000291
ref: 1-4
47111-45000
COVER,FRAME,RIGHT
€ 71.00
2
0912506015
ref: 2
02112-0620A
SCREW (6X20)
€ 2.00
3
0916006039
ref: 3
09160-06109
WASHER (6.5X18X1.6)
€ 2.00
4
0932010008
ref: 4
CUSHION
€ 2.50
5
0918006030
ref: 5
09180-06310
SPACER (6.8X10X10)
€ 2.00
6
4711745000
ref: 6
CUSHION,FRAME COVER
€ 1.50
7-1
6814145000
ref: 7-1
EMBLEM,FRAME COVER
€ 11.50
7-2
6814145010
ref: 7-2
EMBLEM,FRAME COVER
€ 12.50
8
0914803002
ref: 8
NUT
€ 3.00
9
6836326200
ref: 9
LABEL,COMPANY NAME
€ 7.50
10-1
4721145000291
ref: 10-1
47211-45000
COVER,FRAME,LEFT
€ 83.50
10-2
472114500005T
ref: 10-2
47211-45000
COVER,FRAME,LEFT
€ 83.50
10-3
472114500005N
ref: 10-3
47211-45000
COVER,FRAME,LEFT
€ 83.50
10-4
4721145000291
ref: 10-4
47211-45000
COVER,FRAME,LEFT
€ 83.50
11
0912506015
ref: 11
02112-0620A
SCREW (6X20)
€ 2.00
12
0916006039
ref: 12
09160-06109
WASHER (6.5X18X1.6)
€ 2.00
13
0932010008
ref: 13
CUSHION
€ 2.50
14
0918006030
ref: 14
09180-06310
SPACER (6.8X10X10)
€ 2.00
15
4711745000
ref: 15
CUSHION,FRAME COVER
€ 1.50
16-1
6814145000
ref: 16-1
EMBLEM,FRAME COVER
€ 11.50
16-2
6814145010
ref: 16-2
EMBLEM,FRAME COVER
€ 12.50
17
0914803002
ref: 17
NUT
€ 3.00
18
6836326200
ref: 18
LABEL,COMPANY NAME
€ 7.50
