TRANSMISSION
GSXR1000 2005 (K5) USA (E03)
Transmission diagram GSXR1000 2005 (K5) USA (E03)
TRANSMISSION GSXR1000 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
2412040F20
ref: 1
24120-40F21
SHAFT,CNTR
€ 308.00
2
2422140F20
ref: 2
24221-40F30
GEAR,2ND DRIVE
€ 70.50
3
2423140F20
ref: 3
24231-40F30
GEAR,3RD & 4TH
€ 141.50
4
2425140F20
ref: 4
24251-40F30
GEAR,5TH DRIVE
€ 113.00
5
2425235F00
ref: 5
BUSH,5TH DRIVE GEAR
€ 13.00
6
2426140F20
ref: 6
GEAR,6TH DRIVE
€ 113.00
7
2426235F00
ref: 7
BUSH,6TH DRIVE GEAR
€ 19.50
8
0916727003
ref: 8
WASHER,LOCK
€ 5.00
9
0918127014
ref: 9
SHIM(27X36X2.5)
€ 6.00
10
0926106003
ref: 10
PIN(6X10)
€ 1.50
11
0926320087
ref: 11
BEARING(20X34X13.5)
€ 31.50
12
0926725013
ref: 12
BEARING(25X52X20.6)
€ 67.00
13
0928520006
ref: 13
SEAL,OIL(20X31.2X2.7)
€ 7.00
14
0938027004
ref: 14
CIRCLIP
€ 3.50
15
0938027006
ref: 15
CIRCLIP
€ 2.50
16
0938027006
ref: 16
CIRCLIP
€ 2.50
17
0939058001
ref: 17
C RING
€ 2.00
18
2413140F00
ref: 18
SHAFT,DRIVE
€ 282.00
19
2426217E01
ref: 19
BUSH
€ 29.00
20
2426217E01
ref: 20
BUSH
€ 29.00
21
2431140F20
ref: 21
GEAR,1ST DRIVEN
€ 86.00
22
2432140F20
ref: 22
24321-40F30
GEAR,2ND DRIVE
€ 72.50
23
2432202F01
ref: 23
BUSH,2ND DRIVEN GEAR
€ 11.00
24
2433140F20
ref: 24
24331-40F30
GEAR,3RD DRIVE
€ 102.00
25
2433302F00
ref: 25
WASHER,3RD & 4TH DRIVEN
€ 3.50
26
2434140F20
ref: 26
GEAR,4TH DRIVEN
€ 103.50
27
2435140F20
ref: 27
24351-40F30
GEAR,5TH DRIVE
€ 86.00
28
2436140F20
ref: 28
GEAR,6TH DRIVEN
€ 87.50
29
0916027008
ref: 29
WASHER(27X36X1)
€ 3.00
30
0918120251
ref: 30
SHIM(20X34X1)
€ 3.00
31
0918122223
ref: 31
SHIM(22X34X1)
€ 3.00
32
0926106003
ref: 32
PIN(6X10)
€ 1.50
33
0926228025
ref: 33
BEARING(28X70X18)
€ 97.50
34
0926320087
ref: 34
BEARING(20X34X13.5)
€ 31.50
35
0928336008
ref: 35
SEAL,OIL(34.8X70X6)
€ 16.50
36
2431202F00
ref: 36
BUSH
€ 19.50
37
0938027006
ref: 37
CIRCLIP
€ 2.50
38
0938027006
ref: 38
CIRCLIP
€ 2.50
39
0938027006
ref: 39
CIRCLIP
€ 2.50
40
0939070001
ref: 40
C RING
€ 5.50
41
2751021A31
ref: 41
SPROCKET,ENGINE(NT:17)
€ 76.00
42
2753140F00
ref: 42
SPACER,ENG SPROCKET
€ 21.50
43
2760040F10110
ref: 43
CHAIN,DRIVE
€ 216.50
44
2762040F10
ref: 44
JOINT SET,DRIVE CHAIN
€ 18.00
45
0915920004
ref: 45
NUT
€ 12.00
46
0916025035
ref: 46
WASHER(25X40X1.4)
€ 4.00
