FRONT FENDER

GSXR600Z 2002 (K2) USA (E03)

Front fender diagram GSXR600Z 2002 (K2) USA (E03)

FRONT FENDER GSXR600Z 2002 (K2) USA (E03)

FRONT FENDER GSXR600Z 2002 (K2) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

5311035F00019
ref: 1-1

FENDER,FR

€ 240.50

1-2

5311035F00Y7L
ref: 1-2

FENDER,FR

€ 240.50

2

0913906030
ref: 2

SCREW(6X16)

€ 3.50

3

0916106021
ref: 3

WASHER(6.3X16X1.5)

€ 2.50
