CRANKCASE COVER

SV650 2007 (K7) USA (E03)

Crankcase cover diagram SV650 2007 (K7) USA (E03)

CRANKCASE COVER SV650 2007 (K7) USA (E03)

CRANKCASE COVER SV650 2007 (K7) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1134017G00
ref: 1

COVER,CLUTCH

€ 279.50

2

1197133210
ref: 2

LENS,OIL LEVEL CHECK

€ 13.50

3

1148217G00
ref: 3
11482-44H00

GASKET,CLUTCH (NAS)

€ 17.00

4

0421109149
ref: 4

PIN

€ 2.00

5

0910306214
ref: 5

BOLT(6X35)

€ 2.50

6

1197125D00
ref: 6

PLUG,ENGINE OIL FILLER

€ 5.50

7

0928017003
ref: 7

O RING(D:3.1,ID:16.8)

€ 2.00

8

1136117G00
ref: 8

COVER,ENGINE SPROCKET

€ 64.50

9

0910306224
ref: 9

BOLT(6X45)

€ 3.00

10

1135119F50
ref: 10

COVER,MAGNETO

€ 252.50

11

1148319F00
ref: 11

GASKET,MAGNETO COVER (NAS)

€ 11.50

12

0421109149
ref: 12

PIN

€ 2.00

13

0910306214
ref: 13

BOLT(6X35)

€ 2.50

14

0910306239
ref: 14

BOLT(6X65)

€ 3.50

15

0916806023
ref: 15

GASKET(5.8X13X1.2) (NAS)

€ 2.00

16

0925926011
ref: 16

PLUG(26X9)

€ 8.50

17

0928022008
ref: 17

O RING(D:3.1,ID:22.7)

€ 2.50

18

0924816012
ref: 18

PLUG,16X8

€ 4.50

19

0916816002
ref: 19

GASKET(16X22X2) (NAS)

€ 2.00
