HEADLAMP

ref

part #

description

quantity

1-1

3510027620
ref: 1-1

HEADLAMP ASSEMBLY

€ 55.50

1-2

3510027621
ref: 1-2

HEADLAMP ASSEMBLY

€ 30.50

2-1

3512127620
ref: 2-1

LAMP UNIT

€ 72.00

2-2

3512127621
ref: 2-2

LAMP UNIT

€ 68.50

3

3511128610
ref: 3

RIM,HEADLAMP

€ 42.00

4-1

3513619610
ref: 4-1

SCREW,LENS

€ 0.00

4-2

0211105087
ref: 4-2
02112-05087

SCREW

€ 2.00

5

3513512610
ref: 5
35155-48510

NUT,ADJUSTING

€ 2.00

6

3513727620
ref: 6

CUSHION,HEADLAMP

€ 2.00

7

3515127620
ref: 7
35151-06020

SCREW,HEADLAMP ADJUST

€ 2.50

8

3515501321
ref: 8

NUT,HEADLAMP ADJUSTER

€ 2.50

9

3515412610
ref: 9

SPRING,HEADLAMP ADJUST

€ 0.00

10

0221104128
ref: 10
02112-0412A

SCREW

€ 1.50

11

0832121048
ref: 11
08321-0104A

LOCK WASHER

€ 2.00

12

0832221048
ref: 12
08322-01047

WASHER

€ 2.00

13-1

5181026000126
ref: 13-1
51810-26000-13L

HOUSING COMP,HEADLAMP

€ 63.00

13-2

5181026000291
ref: 13-2
51810-26000-13L

HOUSING COMP,HEADLAMP

€ 63.00

14

5182125300
ref: 14
51821-36200

SPACER, HOUSING RH

€ 7.50

15

5182227301
ref: 15

SPACER, HOUSING LH

€ 9.00

16

5182727301
ref: 16
51827-27302

CUSHION,HEADLAMP HOUSING

€ 3.00

17

5184531031
ref: 17

GROMMET,HEADLAMP HOUSING

€ 4.00

17

5184531031
ref: 17

GROMMET,HEADLAMP HOUSING

€ 4.00

18

0122108207
ref: 18
01204-08207

BOLT

€ 3.00

19

0832121088
ref: 19
08321-01087

LOCK WASHER

€ 2.00

20

0832211088
ref: 20
08322-01087

WASHER

€ 2.00

all assemblies
