CRANKCASE

VL800C BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

Crankcase diagram VL800C BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

CRANKCASE VL800C BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)
CRANKCASE VL800C BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)
CRANKCASE VL800C BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)
prices are in EUR
ref
part #
description
quantity
1
1130239821
ref: 1
11302-39822
CRANKCASE SET
€ 2,252.50
2-1
0916048001
ref: 2-1
WASHER(48.1X64X1.94)
0916048001
€ 18.50
2-10
0916048010
ref: 2-10
WASHER(48.1X64X2.16)
0916048010
€ 17.00
2-2
0916048002
ref: 2-2
WASHER(48.1X64X1.96)
0916048002
€ 17.00
2-3
0916048003
ref: 2-3
WASHER(48.1X64X1.99)
0916048003
€ 17.00
2-4
0916048004
ref: 2-4
WASHER(48.1X64X2.01)
0916048004
€ 17.00
2-5
0916048005
ref: 2-5
WASHER(48.1X64X2.04)
0916048005
€ 17.00
2-6
0916048006
ref: 2-6
WASHER(48.1X64X2.06)
0916048006
€ 17.00
2-7
0916048007
ref: 2-7
WASHER(48.1X64X2.09)
0916048007
€ 17.00
2-8
0916048008
ref: 2-8
WASHER(48.1X64X2.11)
0916048008
€ 17.00
2-9
0916048009
ref: 2-9
WASHER(48.1X64X2.14)
0916048009
€ 17.00
3
0920611007
ref: 3
PIN(8.4X11X20)
0920611007
€ 1.50
4
0910308405
ref: 4
BOLT(8X160)
0910308405
€ 6.50
5
0910308406
ref: 5
BOLT(8X120)
€ 2.50
6
0910308179
ref: 6
BOLT(8X105)
0910308179
€ 4.00
7
0910308164
ref: 7
BOLT(8X95)
0910308164
€ 3.50
8
0916806023
ref: 8
GASKET(5.8X13X1.2) (NAS)
0916806023
€ 2.00
9
0916808016
ref: 9
GASKET(8.2X14X1) (NAS)
0916808016
€ 1.00
10
0916810002
ref: 10
GASKET(10X14X3.6) (NAS)
0916810002
€ 2.00
11
0916814002
ref: 11
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
0916814002
€ 2.50
12
0924710008
ref: 12
PLUG(10X12)
0924710008
€ 3.00
13
0924714026
ref: 13
PLUG(14X12)
0924714026
€ 3.50
14
0928004004
ref: 14
O RING(D:1.2,ID:4)
0928004004
€ 2.00
15
0928012009
ref: 15
O RING(D:1.9,ID:12.6)
0928012009
€ 2.50
16
0949320014
ref: 16
JET,OIL GALLERY
0949320014
€ 8.00
17
0949328010
ref: 17
JET,AIR(14)
0949328010
€ 10.50
18
015500610B
ref: 18
BOLT
015500610B
€ 2.50
19
015500640B
ref: 19
BOLT
015500640B
€ 2.00
20
015500812B
ref: 20
BOLT
015500812B
€ 3.50
21
0916808016
ref: 21
GASKET(8.2X14X1) (NAS)
0916808016
€ 1.00
22
015500835B
ref: 22
BOLT
015500835B
€ 3.50
23
015500840B
ref: 23
BOLT
015500840B
€ 3.50
24
015500850B
ref: 24
BOLT
015500850B
€ 2.50
25
015500855B
ref: 25
BOLT
015500855B
€ 3.00
26
015500860B
ref: 26
BOLT
015500860B
€ 3.50
27
015500855B
ref: 27
BOLT
015500855B
€ 3.00
28
015500865B
ref: 28
BOLT
015500865B
€ 3.00
29
0910308105
ref: 29
BOLT(8X95)
0910308105
€ 3.00
30
015500875B
ref: 30
BOLT
015500875B
€ 3.50
31
0910308407
ref: 31
BOLT(8X12)
€ 2.00
32
0916808016
ref: 32
GASKET(8.2X14X1) (NAS)
0916808016
€ 1.00
33
0924712011
ref: 33
PLUG(12X20)
0924712011
€ 4.50
34
0916812002
ref: 34
GASKET(12.1X16.2X3.7) (NAS)
0916812002
€ 2.00
35
0910310706
ref: 35
BOLT(10X135)
€ 7.50
36
0910310705
ref: 36
BOLT(10X160)
0910310705
€ 9.50
37
0915910113
ref: 37
NUT
€ 3.00
38
1145138A00
ref: 38
PIPE,OIL GALLERY
€ 13.50
39
0928015008
ref: 39
O RING(D:3.1,ID:14.8)
0928015008
€ 1.50
40
0910606075
ref: 40
BOLT(6X12)
0910606075
€ 2.50
41
1146138A00
ref: 41
CLAMP,OIL PIPE
€ 1.50
42
0924816013
ref: 42
PLUG
0924816013
€ 4.50
43
0916816002
ref: 43
GASKET(16X22X2) (NAS)
0916816002
€ 2.00
44
1659106B00
ref: 44
16591-06B01
UNION,OIL STAND
1659106B00
€ 6.00
45
3782033D10
ref: 45
SWITCH ASSY,OIL PRESSURE
3782033D10
€ 29.00
46
3782233D00
ref: 46
BOLT,OIL PRESSURE SWITCH
3782233D00
€ 3.00
