MUFFLER

GS450T 1982 (Z) USA (E03)

Muffler diagram GS450T 1982 (Z) USA (E03)

MUFFLER GS450T 1982 (Z) USA (E03)

MUFFLER GS450T 1982 (Z) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1418111010
ref: 1
14181-01D00

GASKET,EXHAUST PIPE (NAS)

€ 8.00

2

0110708358
ref: 2
01500-0835B

BOLT

€ 3.50

3

0832121088
ref: 3
08321-01087

LOCK WASHER

€ 2.00

4-1

1430144101
ref: 4-1
14301-44101-H01

MUFFLER ASSEMBLY

€ 385.00

4-2

1430144110
ref: 4-2
14301-44110-H01

MUFFLER ASSEMBLY

€ 151.50

5-1

1430244101
ref: 5-1
14302-44101-H01

MUFFLER ASSEMBLY

€ 296.00

5-2

1430244110
ref: 5-2
14302-44110-H01

MUFFLER ASSEMBLY

€ 118.50

6

0940235601
ref: 6

CLAMP

€ 5.00

7

0151706258
ref: 7
01550-06257

BOLT

€ 2.50

8

1478044101
ref: 8
14780-44900

COVER,MUFFLER

€ 25.00

9

1479044101
ref: 9
14790-44900

COVER,MUFFLER

€ 33.50

10

0211205088
ref: 10
02112-05087

SCREW

€ 2.00

11

0832121058
ref: 11
08321-0105A

LOCK WASHER

€ 2.00

12

0832221058
ref: 12
08322-01057

WASHER

€ 2.50

13

0211205168
ref: 13
02112-05167

SCREW

€ 2.50
