FUEL TANK (MODEL T)

GS500E 1989 (K) (E01 E02 E04 E15 E16 E17 E21 E22 E24 E25 E34 E39

Fuel tank (model t) diagram GS500E 1989 (K) (E01 E02 E04 E15 E16 E17 E21 E22 E24 E25 E34 E39

FUEL TANK (MODEL T) GS500E 1989 (K) (E01 E02 E04 E15 E16 E17 E21 E22 E24 E25 E34 E39
FUEL TANK (MODEL T) GS500E 1989 (K) (E01 E02 E04 E15 E16 E17 E21 E22 E24 E25 E34 E39
FUEL TANK (MODEL T) GS500E 1989 (K) (E01 E02 E04 E15 E16 E17 E21 E22 E24 E25 E34 E39
prices are in EUR
ref
part #
description
quantity
1-1
4410002DC019A
ref: 1-1
TANK ASSEMBLY,FUEL
€ 642.50

1-2
4410002DC01ZV
ref: 1-2
TANK ASSEMBLY,FUEL
€ 733.00

1-3
4410002DC033J
ref: 1-3
TANK ASSEMBLY,FUEL
€ 690.50

1-4
4410002DD019A
ref: 1-4

E22
TANK ASSY, FUEL (RED)
€ 0.00

1-5
4410002DD01ZV
ref: 1-5

E22
TANK ASSY,FUEL(GREEN)
€ 0.00

1-6
4410002DD033J
ref: 1-6

E22
TANK ASSY, FUEL (BLACK)
€ 0.00

2
6811112C0013L
ref: 2
EMBLEM,FUEL TANK
€ 17.00

3
6824101D00
ref: 3
MOLDING
€ 20.00

4
4420101832
ref: 4
CAP SET,FUEL TANK
€ 108.00

5
0910605017
ref: 5
BOLT(5X20)
€ 2.50

6
4451134A00
ref: 6
CUSHION,FUEL TANK FR
€ 8.50

7
4454548B10
ref: 7
CUSHION,FUEL TANK SIDE
€ 6.50

8
4455001D00
ref: 8
BRACKET COMP,FUEL TANK
€ 17.50

9
0155008403
ref: 9
BOLT
€ 2.50

10
0932014017
ref: 10
CUSHION
€ 2.00

11
0932010038
ref: 11
CUSHION
€ 2.50

12
0918006072
ref: 12
SPACER
€ 2.00

13
0911606172
ref: 13
BOLT(6X30)
€ 1.50

14
4442301D00
ref: 14
HOSE,WATER DRAIN
€ 13.00

5
0910605017
ref: 5
BOLT(5X20)
€ 2.50

6
4451134A00
ref: 6
CUSHION,FUEL TANK FR
€ 8.50

7
4454548B10
ref: 7
CUSHION,FUEL TANK SIDE
€ 6.50

8
4455001D00
ref: 8
BRACKET COMP,FUEL TANK
€ 17.50

9-1
0155008407
ref: 9-1

MODEL R
BOLT
€ 2.50

9-2
0155008403
ref: 9-2

MODEL S
BOLT
€ 2.50

10
0932014017
ref: 10
CUSHION
€ 2.00

11
0932010038
ref: 11
CUSHION
€ 2.50

12-1
0918006180
ref: 12-1

MODEL R
SPACER(6.1X9X18.2)
€ 5.00

12-2
0918006072
ref: 12-2

MODEL S
SPACER
€ 2.00

13-1
0911606078
ref: 13-1

MODEL R
BOLT
€ 1.50

13-2
0911606172
ref: 13-2

MODEL S
BOLT(6X30)
€ 1.50

14
4442301D00
ref: 14
HOSE,WATER DRAIN
€ 13.00

17
0918006180
ref: 17
SPACER(6.1X9X18.2)
€ 5.00

18
0911606078
ref: 18
BOLT
€ 1.50

19
4442301D00
ref: 19
HOSE,WATER DRAIN
€ 13.00
