HEADLAMP (E4,E16,E17,E21,E22,E24,E25,E26,E53)

ref

part #

description

quantity

1-1

3510033240999
ref: 1-1
E4

HEADLAMP ASSY

€ 153.50

1-2

3510033250999
ref: 1-2
E16,E17,E21,E22,E25,

HEADLAMP ASSY

€ 153.50

1-3

3510033230999
ref: 1-3
E24

HEADLAMP ASSEMBLY

€ 0.00

2

3511133240
ref: 2

RIM

€ 40.50

3-1

3512133240
ref: 3-1
E4,E16,E17,E21,E22,E

LAMP UNIT

€ 141.50

3-2

3512133230
ref: 3-2
E24

LAMP UNIT

€ 108.00

4

0211205088
ref: 4

SCREW

€ 2.00

5

3513512610
ref: 5

NUT,ADJUSTING

€ 2.00

6

3517345200
ref: 6

COVER,SOCKET

€ 14.00

7-1

3515133240
ref: 7-1
E4,E24

SCREW,HEADLAMP ADJUST

€ 3.50

7-2

3515133250
ref: 7-2
E16,E17,E21,E22,E25,

SCREW

€ 3.50

8

3515448510
ref: 8

SPRING

€ 2.50

9

3515727630
ref: 9

WASHER

€ 2.50

10

3515248510
ref: 10

NUT,HEADLAMP ADJUSTER

€ 3.00

11

3611849320
ref: 11
E4,E16,E17,E21,E22,E

SOCKET

€ 12.00

12

3611622630
ref: 12
E4,E16,E17,E21,E22,E

JOINT,RUBBER

€ 5.00

13-1

0947112061
ref: 13-1
E4 EXECUTED LOCALLY

BULB (12V, 60/55W, H4)

€ 0.00

13-2

0947112060
ref: 13-2
E4,E16,E17,E21,E22,E

BULB(12V60/55W,H4)

€ 8.00

14

0947112063
ref: 14
E4,E16,E17,E21,E22,E

BULB(12V4W)

€ 6.00

15

0912505022
ref: 15

SCREW

€ 3.50

16

0916205003
ref: 16

WASHER,LOCK

€ 2.00

17

0916906021
ref: 17

WASHER

€ 2.50
