MUFFLER

GSX400E 1984 (E) GENERAL EXPORT (E01)

Muffler diagram GSX400E 1984 (E) GENERAL EXPORT (E01)

MUFFLER GSX400E 1984 (E) GENERAL EXPORT (E01)

MUFFLER GSX400E 1984 (E) GENERAL EXPORT (E01)

prices are in EUR

ref

part #

description

quantity

1

1418111020
ref: 1

GASKET,EXHAUST PIPE (NAS)

€ 8.00

2

0110708408
ref: 2

BOLT 8X40

€ 3.00

3

0832121088
ref: 3

LOCK WASHER

€ 2.00

4

1430144401
ref: 4

MUFFLER ASSY,R

€ 261.50

5

1430244401
ref: 5

MUFFLER ASSY,L

€ 293.00

6

0940235601
ref: 6

CLAMP

€ 5.00

7

0151706258
ref: 7

BOLT

€ 2.50

8

1478044401
ref: 8

COVER,MUFFLER

€ 25.00

9

1479044401
ref: 9

COVER,MUFFLER

€ 33.50

10

0211206108
ref: 10

SCREW

€ 1.50

11

0832121068
ref: 11

LOCK WASHER

€ 2.50

12

0832221068
ref: 12

WASHER

€ 2.00

13

1478544100
ref: 13

CLAMP,MUFFLER COVER

€ 8.50

14

0211205168
ref: 14

SCREW

€ 2.50
