REAR BRAKE

GSX400E 1986 (G) GENERAL EXPORT (E01)

Rear brake diagram GSX400E 1986 (G) GENERAL EXPORT (E01)

REAR BRAKE GSX400E 1986 (G) GENERAL EXPORT (E01)

REAR BRAKE GSX400E 1986 (G) GENERAL EXPORT (E01)

prices are in EUR

ref

part #

description

quantity

1

4311044401
ref: 1

PEDAL,BRAKE

€ 65.50

2

4312011501
ref: 2

ARM,BRAKE PEDAL

€ 21.00

3

0110708258
ref: 3

BOLT

€ 2.50

4

0832121088
ref: 4

LOCK WASHER

€ 2.00

5

0944314020
ref: 5

SPRING

€ 3.00

6

0110706258
ref: 6

BOLT

€ 2.00

7

0831011068
ref: 7

NUT

€ 2.50

8

0110706208
ref: 8

BOLT

€ 2.00

9

0831011068
ref: 9

NUT

€ 2.50

10

4330044401
ref: 10

ROD ASSY,RR BRAKE

€ 16.00

11

0832221067
ref: 11

WASHER

€ 2.00

12

0944009004
ref: 12

SPRING

€ 2.00

13

0920913005
ref: 13

PIN

€ 3.50

14

0915006009
ref: 14

NUT (6MM)

€ 3.50

15

0920006013
ref: 15

PIN(L:13.5)

€ 2.00

16

0411120208
ref: 16

PIN 20X20

€ 1.50

17

0832221067
ref: 17

WASHER

€ 2.00
