TURN SIGNAL LAMP
GZ125 1999 (X) (E01)
Turn signal lamp diagram GZ125 1999 (X) (E01)
TURN SIGNAL LAMP GZ125 1999 (X) (E01)
×
prices are in EUR
ref
part #
description
quantity
1
3560133D30
ref: 1
LAMP ASSY,FR TURN SIGNAL
€ 94.50
2
3561238A01
ref: 2
LENS
€ 10.50
3
3561338A00
ref: 3
GASKET (NAS)
€ 11.50
4
0321104253
ref: 4
SCREW
€ 2.00
5
3562743010
ref: 5
GASKET (NAS)
€ 2.00
6
3561945C10
ref: 6
STAY,TURNSIGNAL FR
€ 97.50
7
0947112045
ref: 7
BULB(12V21W)
€ 5.00
8
3562338A01
ref: 8
SCREW
€ 5.50
9
0831000103
ref: 9
NUT
€ 2.00
10
3567012F00
ref: 10
BRACKET,FR TURNSIGNAL,R
€ 11.00
10
3568012F00
ref: 10
BRACKET,FR TURNSIGNAL,L
€ 11.00
11
0155006123
ref: 11
BOLT
€ 2.50
12
3560333D60
ref: 12
LAMP ASSY,RR TURNSIGNAL
€ 127.50
13
3565238A21
ref: 13
LENS
€ 16.50
14
3561338A00
ref: 14
GASKET (NAS)
€ 11.50
15
0321104253
ref: 15
SCREW
€ 2.00
16
3562743010
ref: 16
GASKET (NAS)
€ 2.00
17
3565945C10
ref: 17
STAY,TURNSIGNAL RR
€ 36.00
18
0947112045
ref: 18
BULB(12V21W)
€ 5.00
19
3562338A01
ref: 19
SCREW
€ 5.50
20
3569517C00
ref: 20
SPACER,RR TURNSIGNAL
€ 3.00
21
0916010501
ref: 21
WASHER(10.5X30X2.3)
€ 2.50
22
0831000103
ref: 22
NUT
€ 2.00
23
3861003F00
ref: 23
RELAY ASSY,TURNSIGNAL LAMP
€ 88.50
