REAR WHEEL (MODEL L/M/N/P/R/S)
RM80X 1987 (H)
Rear wheel (model l/m/n/p/r/s) diagram RM80X 1987 (H)
REAR WHEEL (MODEL L/M/N/P/R/S) RM80X 1987 (H)
×
prices are in EUR
ref
part #
description
quantity
1
6411102B42
ref: 1
HUB,REAR WHEEL
€ 175.00
2
6473102B40
ref: 2
SPACER,RR HUB BEARING
€ 10.50
3
0812360027
ref: 3
BEARING
€ 16.00
4
0926215021
ref: 4
BEARING(15X35X11)
€ 14.00
5
0833141356
ref: 5
CIRCLIP
€ 2.00
6
0928320024
ref: 6
SEAL,OIL(20X35X7)
€ 5.50
7
6921102B40
ref: 7
DISC,REAR BRAKE
€ 147.00
8-1
0212206128
ref: 8-1
MODEL L/M/N/P
SCREW
€ 3.00
8-2
0212206123
ref: 8-2
MODEL R/S
SCREW
€ 3.00
9-1
6972102B40
ref: 9-1
MODEL L/M WITH 2-M6
BRACKET,REAR CALIPER
€ 21.00
9-2
6972102B41
ref: 9-2
MODEL N/P/R/S WITH O
BRACKET,REAR CALIPER
€ 21.00
10
6471102B40
ref: 10
AXLE,RR
€ 34.00
11
6474102B40
ref: 11
SPACER,REAR AXLE
€ 47.00
12
0916014033
ref: 12
WASHER
€ 3.00
13
0914114004
ref: 13
NUT
€ 5.00
14
0411130308
ref: 14
COTTER PIN
€ 1.50
15-1
6451120920
ref: 15-1
SPROCKET,RR(NT:48)
€ 68.50
15-2
6451120980
ref: 15-2
OPT
SPROCKET,RR(NT:46)
€ 174.50
15-3
6451120550
ref: 15-3
OPT
SPROCKET,RR(NT:47)
€ 82.00
15-4
6451102B40
ref: 15-4
OPT
SPROCKET,RR(49T)
€ 79.00
16
0912008010
ref: 16
BOLT(8X30.5)
€ 2.50
17-1
0915908034
ref: 17-1
MODEL L
NUT
€ 2.00
17-2
0915908067
ref: 17-2
MODEL M/N/P/R/S
NUT
€ 5.50
18
6141002B02
ref: 18
ADJUSTER,CHAIN
€ 147.50
19
6142102B00
ref: 19
PLATE,CHAIN ADJUSTER
€ 7.00
20-1
0832221067
ref: 20-1
MODEL L/M/N/P
WASHER
€ 2.00
20-2
0832201063
ref: 20-2
MODEL R/S
WASHER
€ 2.00
21
0831921068
ref: 21
NUT 6MM
€ 2.00
22
6471202B00
ref: 22
WASHER,CHAIN ADJUSTER RH
€ 2.50
23
6471302B00
ref: 23
WASHER,CHAIN ADJUSTER,L
€ 2.00
24
6531102B40
ref: 24
RIM,RR WHEEL(1.60X14 AL)
€ 169.50
25-1
6532002B40
ref: 25-1
MODEL L
SPOKE SET,RR WHEEL
€ 35.50
25-2
6532002B50
ref: 25-2
MODEL M/N/P/R
SPOKE SET,REAR WHEEL
€ 42.00
25-3
6532002B51
ref: 25-3
MODEL S
SPOKE ASSY,RR WHEEL
€ 42.00
26
6511002B40
ref: 26
TIRE,RR(90/100 14)
€ 52.50
27
6520002B40
ref: 27
TUBE ASSY,WHEEL INNER
€ 26.00
28
6526102B40
ref: 28
PROTECTOR,WHL INR TUBE
€ 3.00
29-1
6527046910
ref: 29-1
@r65270-43D00
STOPPER,BEAD
€ 30.50
29-2
6527043D00
ref: 29-2
STOPPER,BEAD(1.85)
€ 30.50
30-1
0832211088
ref: 30-1
MODEL L/M/N/P
WASHER
€ 2.00
30-2
0832201083
ref: 30-2
MODEL R/S
WASHER
€ 1.50
31-1
0831012088
ref: 31-1
MODEL L/M/N/P
NUT
€ 2.00
31-2
0831000083
ref: 31-2
MODEL R/S
NUT
€ 1.50
32
0981600126
ref: 32
SPARK PLUG WRENCH 21 & SPANNER 5.1
€ 10.00
32
5526124010
ref: 32
PROTECTOR,INNER TUBE
€ 9.50
33
6531102B00
ref: 33
RIM,REAR WHEEL (1.60X14)
€ 149.00
34
6532020410
ref: 34
SPOKE SET
€ 29.50
35
6527046910
ref: 35
STOPPER,BEAD
€ 30.50
36
0831012088
ref: 36
NUT
€ 2.00
37
0832211088
ref: 37
WASHER
€ 2.00
38
0981600126
ref: 38
MODEL K
SPARK PLUG WRENCH 21 & SPANNER 5.1
€ 10.00
