CRANKCASE COVER - WATER PUMP (MODEL K/L/M/N/P/R/S)
RM80X 1988 (J)
Crankcase cover - water pump (model k/l/m/n/p/r/s) diagram RM80X 1988 (J)
CRANKCASE COVER - WATER PUMP (MODEL K/L/M/N/P/R/S) RM80X 1988 (J)
×
prices are in EUR
ref
part #
description
quantity
1-1
1134102B40
ref: 1-1
MODEL K/L/M/N
COVER,CLUTCH
€ 142.00
1-2
1134102B42
ref: 1-2
MODEL P/R/S
COVER,CLUTCH
€ 142.00
2
1148227C00
ref: 2
GASKET,CLUTCH COVER (NAS)
€ 12.00
3
0421109129
ref: 3
PIN
€ 2.00
4-1
0154706257
ref: 4-1
MODEL K/L/M/N/P
BOLT
€ 2.50
4-2
0154706253
ref: 4-2
MODEL R/S
SCREW
€ 2.50
5-1
0154706357
ref: 5-1
MODEL K/L/M/N/P
BOLT
€ 2.50
5-2
0154706353
ref: 5-2
MODEL R/S
BOLT
€ 3.00
6
0920020810
ref: 6
PLUG SET
€ 8.00
7
0912806004
ref: 7
SCREW(6X10)
€ 1.50
8
0916806004
ref: 8
GASKET(6.2X11X1).2 (NAS)
€ 1.50
9-1
1135102B40
ref: 9-1
MODEL K/L/M/N
COVER,MAGNETO
€ 60.00
9-2
1135102B41
ref: 9-2
MODEL P/R/S
COVER,MAGNETO
€ 60.00
10-1
1148302B01H17
ref: 10-1
MODEL K
GASKET,MAGNETO COVER (NAS)
€ 5.00
10-2
1148302B50
ref: 10-2
MODEL L/M/N/P/S
GASKET,MAGNETO COVER (NAS)
€ 5.00
11-1
0154706257
ref: 11-1
MODEL K/L/M/N/P
BOLT
€ 2.50
11-2
0154706253
ref: 11-2
MODEL R/S
SCREW
€ 2.50
12-1
1741002B42
ref: 12-1
MODEL K/L
CASE,WATER PUMP
€ 59.00
12-2
1741002B44
ref: 12-2
MODEL M/N/P/R/S
CASE,WATER PUMP
€ 59.00
13
1741543000
ref: 13
@l17415-00B00
BOLT, DRAIN
€ 0.00
14
1741328C10
ref: 14
@l17413-00B00
WASHER
€ 1.50
15
1743102B41
ref: 15
GASKET,WATER PUMP CASE (NAS)
€ 5.00
16-1
0421109109
ref: 16-1
MODEL K/L
PIN
€ 2.00
16-2
0421109129
ref: 16-2
MODEL M/N/P/R/S
PIN
€ 2.00
17-1
0154706207
ref: 17-1
MODEL K/L/M/N/P
BOLT
€ 2.50
17-2
0154706203
ref: 17-2
MODEL R/S
SCREW
€ 2.50
18-1
0154706307
ref: 18-1
MODEL K/L/M/N/P
BOLT
€ 2.50
18-2
0154706303
ref: 18-2
MODEL R/S
BOLT,G/S SWITC
€ 3.00
19
1749102B40
ref: 19
IMPELLER,WATER PUMP
€ 17.50
20
0928212006
ref: 20
MODEL K
SEAL,OIL(12X24X3.6)
€ 7.00
21
0928912004
ref: 21
MODEL K
SEAL,OIL(12X24X6.4)
€ 9.00
22
0833141249
ref: 22
MODEL K
CIRCLIP
€ 2.50
23
1746128C10
ref: 23
MODEL L/M/N/P/R/S
SEAL,WATER PUMP OIL
€ 7.00
24
0811306980
ref: 24
BEARING
€ 14.00
25
0938119003
ref: 25
CIRCLIP
€ 2.00
26
0833131086
ref: 26
CIRCLIP
€ 2.00
