TURN SIGNAL LAMP
SP500 1983 (D) USA (E03)
Turn signal lamp diagram SP500 1983 (D) USA (E03)
TURN SIGNAL LAMP SP500 1983 (D) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3560137430
ref: 1
LAMP ASSEMBLY,FRONT TURN SIGNAL
€ 31.00
2
3561248530
ref: 2
35612-01A70
LENS
€ 7.50
3
3561328620
ref: 3
GASKET (NAS)
€ 7.00
4
0321104258
ref: 4
03211-0425B
SCREW TAPP.
€ 2.00
5
3562743010
ref: 5
GASKET (NAS)
€ 2.00
6
0947106011
ref: 6
BULB(6V17W,STANLEY,A4513A)
€ 9.50
7
0832121128
ref: 7
08321-01127
WASHER,LOCK 12
€ 2.50
8
0831012128
ref: 8
09140-12039
NUT
€ 3.00
9
3560337430
ref: 9
LAMP ASSY,RR TURNSIGNAL
€ 0.00
10
3561248530
ref: 10
35612-01A70
LENS
€ 7.50
11
3561328620
ref: 11
GASKET (NAS)
€ 7.00
12
0321104258
ref: 12
03211-0425B
SCREW TAPP.
€ 2.00
13
3562743010
ref: 13
GASKET (NAS)
€ 2.00
14
0947106011
ref: 14
BULB(6V17W,STANLEY,A4513A)
€ 9.50
15
0832121128
ref: 15
08321-01127
WASHER,LOCK 12
€ 2.50
16
0831012128
ref: 16
09140-12039
NUT
€ 3.00
17
3562037400
ref: 17
BRACKET,REAR TURN SIGNAL
€ 5.50
18
3564037400
ref: 18
BRACKET,REAR TURN SIGNAL
€ 5.50
19
3861048600
ref: 19
38610-05X50
RELAY,TURN SIGNAL
€ 46.50
