prices are in EUR
ref
part #
description
quantity
1-1
SWING ARM ASSEMBLY,REAR
1-2
SWING ARM ASSEMBLY,REAR
2-1
BUSHING
2-2
BUSH
3
SPACER,SWING ARM,CENTER
4
NIPPLE,GREASE
5
SPACER,RR SWGARM PIVOT
6
COVER,SWGARM BUSH DUST SEAL
7
O RING(D:2,ID:24.5)
8
WASHER(12.5X24X2.3)
9-1
SHAFT,REAR SWING ARM
9-2
SHAFT,PIVOT
10
NUT
11
WASHER
12-2
CASE,CHAIN
13
CUSHION
14
SPACER (7X9X7)
15
WASHER (6.5X20X1.2)
17-1
ABSORBER ASSEMBLY,REAR SHOCK
17-2
ABSORBER ASSEMBLY,REAR SHOCK
17-3
ABSORBER ASSEMBLY,REAR SHOCK
18
NUT
19
WASHER
20
WASHER
21
TORQUE LINK,REAR
22
RETAINER,SNAP
23
CLIP
24
BOLT(8X26.5)
25
LOCK WASHER
26
NUT
27
BOLT(8X22)
28
WASHER 5MM
29-1
BUFFER,CHAIN TOUCH DEFLECTOR
29-2
BUFFER,CHAIN TOUCH DEFENSE
30
NO PRODUCT DESCRIPTION AVAILABLE
33
LOCK WASHER
34
WASHER
