Buy Suzuki VS Parts Online


REAR COMBINATION LAMP

VS1400GLP INTRUDER 1987 (H) USA (E03)

Rear combination lamp diagram VS1400GLP INTRUDER 1987 (H) USA (E03)

REAR COMBINATION LAMP VS1400GLP INTRUDER 1987 (H) USA (E03)
REAR COMBINATION LAMP VS1400GLP INTRUDER 1987 (H) USA (E03)
REAR COMBINATION LAMP VS1400GLP INTRUDER 1987 (H) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
3571038B30
ref: 1
LAMP ASSY,RR COMBINATION
3571038B30
€ 118.00
2
3571238B30
ref: 2
LENS
3571238B30
€ 30.00
3
3571338B30
ref: 3
GASKET (NAS)
3571338B30
€ 6.50
4
3572338B30
ref: 4
03511-0416A
SCREW
€ 1.50
5
0947112129
ref: 5
BULB(12V27/8W)
0947112129
€ 10.00
6
0932009018
ref: 6
CUSHION
0932009018
€ 2.00
7
0918006090
ref: 7
09180-06264
SPACER (6.4X9X10.5)
€ 2.00
8-1
0916006060
ref: 8-1
09160-06077
WASHER
0916006060
€ 2.00
8-2
0916006077
ref: 8-2
WASHER(6.5X20X1.2)
0916006077
€ 2.00
9
0831620063
ref: 9
08316-2006A
NUT
0831620063
€ 2.00
10
3591038B30
ref: 10
LAMP ASSY,LICENSE
3591038B30
€ 121.00
11
3591738B30
ref: 11
COVER,LICENSE LAMP
3591738B30
€ 21.00
12
3591238B30
ref: 12
LENS,LICENSE LAMP
€ 10.50
13
3591338B30
ref: 13
GASKET,LICENSE LAMP (NAS)
€ 5.00
14
0321104207
ref: 14
SCREW
0321104207
€ 1.50
15
0947112130
ref: 15
BULB(12V7.5W)
€ 2.50
16
3576238B30
ref: 16
CUSHION
€ 0.00
17
3576638B30
ref: 17
SPACER
€ 0.00
18-1
0916006060
ref: 18-1
09160-06077
WASHER
0916006060
€ 2.00
18-2
0916006077
ref: 18-2
WASHER(6.5X20X1.2)
0916006077
€ 2.00
19
0831620063
ref: 19
08316-2006A
NUT
0831620063
€ 2.00
20
0930812009
ref: 20
GROMMET
0930812009
€ 3.00
21
0940406429
ref: 21
CLAMP(L:45)
€ 2.50
22
3597038B00
ref: 22
REFLEX REFLECTOR ASSY,RR
3597038B00
€ 27.00
23
0831610053
ref: 23
08316-1005A
NUT
0831610053
€ 2.50
24
3597738B10
ref: 24
35977-38B12
SPACER
€ 5.00
25
0214205123
ref: 25
02142-0512A
SCREW 5X12
0214205123
€ 1.50
26
0831000053
ref: 26
08310-0005A
NUT
€ 2.50
27
3597038B00
ref: 27
REFLEX REFLECTOR ASSY,RR
3597038B00
€ 27.00
28
3597738B00
ref: 28
35977-38B30
SPACER
€ 3.00
29
0832201053
ref: 29
08322-0105A
WASHER
0832201053
€ 2.50
30-1
0831000053
ref: 30-1
08310-0005A
NUT
€ 2.50
30-2
0831610053
ref: 30-2
08316-1005A
NUT
0831610053
€ 2.50
31
3692002200
ref: 31
COVER,HARNESS
3692002200
€ 3.00
