Buy Suzuki VS Parts Online


STEERING STEM (MODEL Y/K1/K2/K3)

VS1400GLP INTRUDER 1997 (V) USA (E03)

Steering stem (model y/k1/k2/k3) diagram VS1400GLP INTRUDER 1997 (V) USA (E03)

STEERING STEM (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 1997 (V) USA (E03)
STEERING STEM (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 1997 (V) USA (E03)
STEERING STEM (MODEL Y/K1/K2/K3) VS1400GLP INTRUDER 1997 (V) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
5141038B21
ref: 1
STEM,STEERING
€ 544.00
2
0926530009
ref: 2
BEARING(30X55X17)
0926530009
€ 49.50
3
0713010307
ref: 3
BOLT
0713010307
€ 4.50
4
0926525019
ref: 4
BEARING(25X47X15)
0926525019
€ 48.50
5
5164349002
ref: 5
SEAL,STEERING UPR DUST
5164349002
€ 7.50
6
5163128000
ref: 6
NUT,STEERING STEM(25X44X10)
5163128000
€ 12.50
7
5131139A10
ref: 7
BRACKET,FR FORK UPR
€ 343.50
8
5135324B00
ref: 8
NUT,CAP
5135324B00
€ 21.50
9
5135624B01
ref: 9
WASHER(22.5X32X1.6)
5135624B01
€ 3.00
10
5623138A50
ref: 10
STAY,HANDLE
5623138A50
€ 49.50
11
5622138A01
ref: 11
HOLDER,HANDLE LWR
5622138A01
€ 65.00
12
0713010257
ref: 12
BOLT
0713010257
€ 3.00
13
5621138A01
ref: 13
HOLDER,HANDLE UPR
5621138A01
€ 45.00
14-1
0713008253
ref: 14-1
07130-0825B
BOLT
0713008253
€ 3.50
14-2
0713008307
ref: 14-2
BOLT
0713008307
€ 4.50
15
0925006009
ref: 15
CAP(OD:14.5)
0925006009
€ 3.50
16
5624038A42
ref: 16
DAMPER,RUBBER
5624038A42
€ 31.50
17
5624239A12
ref: 17
CUSHION,RUBBER UNDER
5624239A12
€ 42.50
18
5135438A40
ref: 18
WASHER
5135438A40
€ 9.00
19
0915910027
ref: 19
NUT
0915910027
€ 3.00
20
5190038810
ref: 20
LOCK SET,STEERING
5190038810
€ 168.50
