RIGHT HANDLE LEVER

DR-Z400E 2007 (K7) USA (E03) DRZ400E DR Z400E

Right handle lever diagram DR-Z400E 2007 (K7) USA (E03) DRZ400E DR Z400E

RIGHT HANDLE LEVER DR-Z400E 2007 (K7) USA (E03) DRZ400E DR Z400E
RIGHT HANDLE LEVER DR-Z400E 2007 (K7) USA (E03) DRZ400E DR Z400E
RIGHT HANDLE LEVER DR-Z400E 2007 (K7) USA (E03) DRZ400E DR Z400E
prices are in EUR
ref
part #
description
quantity
1
5711014D11
ref: 1
GRIP,THROTTLE
5711014D11
€ 25.50
2
5710014D00
ref: 2
CASE ASSY,THROTTLE
5710014D00
€ 24.00
3
0912505066
ref: 3
SCREW(5X25)
0912505066
€ 2.00
4
0211205203
ref: 4
02112-0520B
SCREW
0211205203
€ 2.50
5
5742136E10
ref: 5
LEVER,BRAKE
5742136E10
€ 38.50
6
5743114500
ref: 6
BOLT,BRAKE LEVER
5743114500
€ 4.00
7
0831610063
ref: 7
08316-1006B
NUT
0831610063
€ 2.50
8
5743036E00
ref: 8
BOLT,ADJUSTER
5743036E00
€ 5.00
9
5731814502
ref: 9
SPRING,RETURN
5731814502
€ 3.00
10
5734136E00
ref: 10
COVER,BRAKE LEVER
5734136E00
€ 14.50
