FOOTREST

RM-Z450 2007 (K7) USA (E03) RMZ450 RM Z450

Footrest diagram RM-Z450 2007 (K7) USA (E03) RMZ450 RM Z450

FOOTREST RM-Z450 2007 (K7) USA (E03) RMZ450 RM Z450

FOOTREST RM-Z450 2007 (K7) USA (E03) RMZ450 RM Z450

prices are in EUR

ref

part #

description

quantity

1

4231035G00
ref: 1

STAND

€ 84.50

2

4355135G00
ref: 2

FOOTREST,R

€ 143.00

3

4356135G00
ref: 3

FOOTREST,L

€ 210.00

4

0920010022
ref: 4

PIN

€ 8.50

5

0944821009
ref: 5

SPRING

€ 6.50

6

0944821010
ref: 6

SPRING

€ 6.50

7

0832201103
ref: 7
08322-0110A

WASHER

€ 2.50

8-1

0938510005
ref: 8-1

CLIP

€ 1.50

8-2

041112520A
ref: 8-2

PIN

€ 2.00

9

4185535G00
ref: 9

BRACKET,FOOTREST,R

€ 70.50

10

4186535G00
ref: 10

BRACKET,FOOTREST,L

€ 70.50

11

0910310366
ref: 11

BOLT(10X30)

€ 3.00
