Buy Suzuki DL Parts Online


HANDLEBAR (MODEL K4/K5/K6)

DL1000 VSTROM 2005 (K5) USA (E03)

Handlebar (model k4/k5/k6) diagram DL1000 VSTROM 2005 (K5) USA (E03)

HANDLEBAR (MODEL K4/K5/K6) DL1000 VSTROM 2005 (K5) USA (E03)
HANDLEBAR (MODEL K4/K5/K6) DL1000 VSTROM 2005 (K5) USA (E03)
HANDLEBAR (MODEL K4/K5/K6) DL1000 VSTROM 2005 (K5) USA (E03)
prices are in EUR
ref
part #
description
quantity
1-1
5611106G10
ref: 1-1
HANDLEBAR
5611106G10
€ 200.00
1-2
5611106G00
ref: 1-2
HANDLEBAR
5611106G00
€ 199.00
2
5620006860
ref: 2
56200-06861
BALANCER,HANDL
5620006860
€ 44.50
3
0912706023
ref: 3
SCREW(6X140)
0912706023
€ 3.50
4
5734614G00
ref: 4
SPACER,KNUCKLE COVER
5734614G00
€ 9.50
5
5627206G00
ref: 5
EXPANDER
5627206G00
€ 5.50
6
5627617D00
ref: 6
SPACER,EXPANDER
5627617D00
€ 2.50
7
0916006130
ref: 7
WASHER(6.5X16X1.6)
0916006130
€ 2.00
8
5627210G00
ref: 8
EXPANDER,HANDLE BALANCER
5627210G00
€ 3.00
9
5627310G00
ref: 9
56273-10G10
NUT,HANDLE BAL
5627310G00
€ 6.50
10
5650004F20
ref: 10
56500-04F23
MIRROR ASSY,RH
5650004F20
€ 180.50
11
5660004F20
ref: 11
56600-04F23
MIRROR ASSY,LH
5660004F20
€ 180.50
12-1
5830006G10
ref: 12-1
58300-06G11
CABLE ASSY,THR
5830006G10
€ 130.00
12-2
5830006G11
ref: 12-2
CABLE ASSY,THROTTLE
€ 130.00
13
5862106G00
ref: 13
GUIDE,THROTTLE CABLE
€ 9.00
14
0216206123
ref: 14
02162-0612A
BOLT
€ 1.50
