REAR SWINGING ARM

GP125U 1978 (C) (E01 E02 E04 E06 E13 E14 E17 E18 E21 E22 E24 E32

Rear swinging arm diagram GP125U 1978 (C) (E01 E02 E04 E06 E13 E14 E17 E18 E21 E22 E24 E32

prices are in EUR

ref

part #

description

quantity

6110039832019
ref: 1
FROM 61100-39831-019

REAR SWINGING ARM SET

€ 104.50

0931912018
ref: 2

BUSH(12X24X44)

€ 9.00

6121139000
ref: 3

SHAFT,REAR SWING ARM

€ 15.00

0916012001
ref: 4

WASHER(12.5X32X2.3)

€ 2.50

0832211128
ref: 5

WASHER

€ 2.00

0915912102
ref: 6

NUT

€ 5.00

6127339600
ref: 7

BUFFER,CHAIN TOUCH DEFENSE

€ 8.00

6210039230
ref: 14

ABSORBER ASSY, REAR SHOCK

€ 136.50

0831311108
ref: 16

NUT, LOWER LH

€ 2.50

17-1

0832211128
ref: 17-1

WASHER

€ 2.00

0916010001
ref: 18

WASHER

€ 2.00

0916010033
ref: 19

WASHER(10.5X24X3.2)

€ 2.00

0916012012
ref: 20

WASHER (12.5X24X3.2)

€ 2.50

6431039000
ref: 22

TORQUE LINK, REAR

€ 13.50

0911108012
ref: 23

BOLT(8X22.5)

€ 3.00

0911108013
ref: 24

BOLT(8X26.5)

€ 3.00

0832121088
ref: 25

LOCK WASHER

€ 2.00

0914008008
ref: 26

NUT

€ 1.50

0938510001
ref: 27

CLIP

€ 1.50
