FOOTREST (GS750N
GS750B 1979 (N) USA (E03)
Footrest (gs750n diagram GS750B 1979 (N) USA (E03)
FOOTREST (GS750N GS750B 1979 (N) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4351045010019
ref: 1
BAR,FRONT FOOTREST
€ 45.50
2
4352045010019
ref: 2
BAR,FRONT FOOTREST,LEFT
€ 17.50
3
0931910008
ref: 3
BUSH
€ 8.00
4
0910410007
ref: 4
09104-10029
BOLT
€ 3.50
5
0916010013
ref: 5
09160-10123
WASHER (10.1X21X2.3)
€ 2.00
6
0832121108
ref: 6
08321-01107
LOCK WASHER
€ 2.00
7
4351645010
ref: 7
BAR,FRONT FOOTREST,RIGHT NO
€ 17.00
8
4352645010
ref: 8
BAR,FRONT FOOTREST,LEFT NO
€ 19.00
9
4355145010
ref: 9
RUBBER,FR FOOTREST
€ 41.50
10
0920008029
ref: 10
PIN
€ 3.50
11
0832211088
ref: 11
08322-01087
WASHER
€ 2.00
12
0411120208
ref: 12
04111-2020A
PIN 20X20
€ 1.50
13
0944819007
ref: 13
09448-19010
SPRING
€ 3.00
14
0944819008
ref: 14
09448-19011
SPRING
€ 2.50
15
0110706208
ref: 15
01500-06207
BOLT
€ 2.00
16
0831921068
ref: 16
08319-2106A
NUT 6MM
€ 2.00
17
4361045000
ref: 17
43610-45001
BAR,REAR FOOTREST
€ 21.50
18
4362045000
ref: 18
43620-45001
BAR,REAR FOOTREST
€ 13.50
19
4361245000
ref: 19
43612-45001
RUBBER,PILLION FOOTREST
€ 15.00
20
4362245000
ref: 20
43612-45001
RUBBER, LH
€ 15.00
21
4363145000
ref: 21
43631-45001
WASHER,REAR FOOTREST RUBBER
€ 16.00
22
0920006010
ref: 22
PIN
€ 2.50
23
0411120208
ref: 23
04111-2020A
PIN 20X20
€ 1.50
