CHAIN CASE - SHOCK ABSORBER

GS750EC 1977 (B) USA (E03)

Chain case - shock absorber diagram GS750EC 1977 (B) USA (E03)

CHAIN CASE - SHOCK ABSORBER GS750EC 1977 (B) USA (E03)
CHAIN CASE - SHOCK ABSORBER GS750EC 1977 (B) USA (E03)
CHAIN CASE - SHOCK ABSORBER GS750EC 1977 (B) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
6131145000019
ref: 1
61311-45200
CASE,CHAIN
€ 99.00
2
6138145000
ref: 2
REINFORCEMENT,CHAIN CASE
6138145000
€ 42.00
3
0910006011
ref: 3
BOLT(6X8)
0910006011
€ 2.50
4
0916906010
ref: 4
WASHER
0916906010
€ 3.00
5
0110706258
ref: 5
01500-06257
BOLT
€ 2.00
6
0832121068
ref: 6
08321-01067
LOCK WASHER
0832121068
€ 2.50
7
0110706108
ref: 7
01500-06107
BOLT
€ 2.00
8
0916006028
ref: 8
WASHER(6.5X18X1)
0916006028
€ 1.50
9
0932008005
ref: 9
09161-08006
CUSHION
€ 2.00
10
0918006032
ref: 10
09180-06246
SPACER (6.1X8X5.2)
0918006032
€ 2.50
11-1
6210045730
ref: 11-1
62100-45410
ABSORBER ASSEMBLY,REAR SHOCK
€ 233.50
11-2
6210045030
ref: 11-2
62100-45410
ABSORBER ASSEMBLY,REAR SHOCK
€ 233.50
11-3
6210045031
ref: 11-3
62100-45410
ABSORBER ASSEMBLY,REAR SHOCK
€ 233.50
12
0831311108
ref: 12
08313-10107
NUT, LOWER LH
0831311108
€ 2.50
13
0832211128
ref: 13
08322-01127
WASHER
0832211128
€ 2.00
14
0916012012
ref: 14
09160-12082
WASHER (12.5X24X3.2)
0916012012
€ 2.50
15
0916010001
ref: 15
09160-10093
WASHER
0916010001
€ 2.00
16
0916010033
ref: 16
09160-10128-XC0
WASHER(10.5X24X3.2)
0916010033
€ 2.00
17
0910410002
ref: 17
BOLT(10X36)
0910410002
€ 4.50
18
0832211108
ref: 18
08322-01107
WASHER
€ 2.50
