Buy Suzuki GSF Parts Online


CAM SHAFT / VALVE

GSF1200 BANDIT 2003 (K3) USA (E03)

Cam shaft / valve diagram GSF1200 BANDIT 2003 (K3) USA (E03)

CAM SHAFT / VALVE GSF1200 BANDIT 2003 (K3) USA (E03)
CAM SHAFT / VALVE GSF1200 BANDIT 2003 (K3) USA (E03)
CAM SHAFT / VALVE GSF1200 BANDIT 2003 (K3) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
1271126D00
ref: 1
CAMSHAFT,INTAKE
1271126D00
€ 488.00
2
1274126D00
ref: 2
SPROCKET,CAMSHAFT
1274126D00
€ 52.00
3
0910307001
ref: 3
BOLT(7X11)
0910307001
€ 2.00
4
1272126E20
ref: 4
CAMSHAFT,EXHAUST
1272126E20
€ 452.50
5
1274126D00
ref: 5
SPROCKET,CAMSHAFT
1274126D00
€ 52.00
6
0910307001
ref: 6
BOLT(7X11)
0910307001
€ 2.00
7
1284027A01
ref: 7
ARM,VALVE ROCKER
1284027A01
€ 49.50
8
1284249201
ref: 8
SCREW,TAPPET ADJUSTING
1284249201
€ 5.50
9
1284327A00
ref: 9
NUT,TAPPET ADJUSTING
1284327A00
€ 3.00
10
1286127A00
ref: 10
SHAFT,VALVE ROCKER ARM
1286127A00
€ 31.00
11
0944013014
ref: 11
SPRING
0944013014
€ 2.50
12
0911206004
ref: 12
01800-06303
BOLT(6X30)
€ 1.50
13
0832201063
ref: 13
08322-0106B
WASHER
0832201063
€ 2.00
14
1291106B02
ref: 14
VALVE,INTAKE
1291106B02
€ 84.00
15
1291206B00
ref: 15
VALVE,EXHAUST
1291206B00
€ 85.50
16
1292006B00
ref: 16
SPRING SET,VALVE
1292006B00
€ 14.00
17
1293127A20
ref: 17
RETAINER,VALVE SPRING
1293127A20
€ 5.50
18
1293381400
ref: 18
SEAT,VALVE SPRING
1293381400
€ 4.00
19
1293427A01
ref: 19
SEAT,VALVE SPRING EXH INNER
1293427A01
€ 7.00
20
1293527A00
ref: 20
SEAT,VALVE SPRING EXH OUTER
1293527A00
€ 3.50
21
1293227A00
ref: 21
COTTER VALVE
1293227A00
€ 2.50
22
0928905011
ref: 22
SEAL,OIL(5X10X9.7)
0928905011
€ 6.00
23
1113727A02
ref: 23
PLATE,VALVE SEAT
1113727A02
€ 7.50
