MUFFLER

GSF1200S BANDIT 2002 (K2) USA (E03)

Muffler diagram GSF1200S BANDIT 2002 (K2) USA (E03)

MUFFLER GSF1200S BANDIT 2002 (K2) USA (E03)
MUFFLER GSF1200S BANDIT 2002 (K2) USA (E03)
MUFFLER GSF1200S BANDIT 2002 (K2) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
1410032F10
ref: 1
14100-32F11
EXHAUST COMP
€ 1,138.50
2
1418118C00
ref: 2
GASKET,EXHAUST (NAS)
1418118C00
€ 6.50
3
0910608165
ref: 3
BOLT(8X25)
0910608165
€ 5.00
4
1477127E00
ref: 4
CONNECTOR,MUFFLER
1477127E00
€ 29.00
5
0155008403
ref: 5
01550-0840A
BOLT
0155008403
€ 3.50
6-1
1431032F10H01
ref: 6-1
BODY,MUFFLER
1431032F10H01
€ 842.50
6-2
1430532F30H01
ref: 6-2
MUFFLER
€ 441.50
6-3
1430532F20
ref: 6-3
MUFFLER
1430532F20
€ 1,015.00
7
0911808068
ref: 7
09118-08145
BOLT 8X40
€ 7.50
8
0918008152
ref: 8
SPACER(8.6X12X24.2)
0918008152
€ 6.00
9
0932012048
ref: 9
CUSHION
0932012048
€ 5.00
10-1
0910308386
ref: 10-1
BOLT(8X50)
0910308386
€ 3.00
10-2
0910308358
ref: 10-2
BOLT(8X45)
0910308358
€ 3.50
11-1
0916008140
ref: 11-1
09160-08146
WASHER (8.5X33X1.6)
0916008140
€ 3.00
11-2
0916008140
ref: 11-2
09160-08146
WASHER (8.5X33X1.6)
0916008140
€ 3.00
12
0918008213
ref: 12
SPACER(8.5X12X30.1)
0918008213
€ 5.50
13
0932012069
ref: 13
CUSHION
0932012069
€ 8.50
14
0836125088
ref: 14
08361-2508A
NUT
0836125088
€ 2.50
