Buy Suzuki GSF Parts Online


HANDLE SWITCH (MODEL K4/K5)

GSF1200Z BANDIT 2001 (K1) USA (E03)

Handle switch (model k4/k5) diagram GSF1200Z BANDIT 2001 (K1) USA (E03)

HANDLE SWITCH (MODEL K4/K5) GSF1200Z BANDIT 2001 (K1) USA (E03)
HANDLE SWITCH (MODEL K4/K5) GSF1200Z BANDIT 2001 (K1) USA (E03)
HANDLE SWITCH (MODEL K4/K5) GSF1200Z BANDIT 2001 (K1) USA (E03)
prices are in EUR
ref
part #
description
quantity
1-1
3720027E51
ref: 1-1
SWITCH ASSY,HANDLE,R
3720027E51
€ 158.50
1-2
3720017G10
ref: 1-2
SWITCH ASSY,HANDLE,R
3720017G10
€ 169.50
2
0211205303
ref: 2
02112-0530A
SCREW
0211205303
€ 1.50
3
0211205503
ref: 3
02112-0550B
SCREW
0211205503
€ 2.00
4
0211205103
ref: 4
02112-0510A
SCREW
0211205103
€ 2.00
5
3740024F10
ref: 5
SWITCH ASSY,HANDLE,L
3740024F10
€ 228.00
6
0211205253
ref: 6
02112-0525A
SCREW
0211205253
€ 1.50
7
0211205453
ref: 7
02112-0545B
SCREW
0211205453
€ 4.00
