REAR CALIPER
GSF1200Z BANDIT 2004 (K4) USA (E03)
Rear caliper diagram GSF1200Z BANDIT 2004 (K4) USA (E03)
REAR CALIPER GSF1200Z BANDIT 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6910005CG0999
ref: 1
CALIPER ASSY,RR
€ 770.50
2
6910005850
ref: 2
69100-05851
PISTON SET
€ 122.50
3
6910032820
ref: 3
69101-05840
SEAL SET,PISTON
€ 26.00
4
5914505C50
ref: 4
BOLT,HOUSING
€ 9.50
5
5914316700
ref: 5
SPRING
€ 7.50
6
6914146E01
ref: 6
PIN,PAD
€ 9.00
7
6914246E01
ref: 7
CLIP,PAD PIN
€ 14.00
8
5915116701
ref: 8
COVER
€ 13.50
9
5912118410
ref: 9
BLEEDER
€ 8.00
10
5515666310
ref: 10
CAP,BLEEDER PLUG
€ 6.00
11
6910105890
ref: 11
PAD & SHIM SET (NAS)
€ 64.00
12
5937120C00
ref: 12
SHIM,INNER
€ 7.50
13
5938120C00
ref: 13
SHIM,OUTER
€ 7.50
14-1
0155008303
ref: 14-1
01550-0830A
BOLT
€ 3.00
14-2
0910308359
ref: 14-2
BOLT(8X28)
€ 4.00
