FRONT BRAKE HOSE (GSF1250SAK7/SAK8/SAK9)

GSF1250S BANDIT 2009 (K9) USA (E03)

Front brake hose (gsf1250sak7/sak8/sak9) diagram GSF1250S BANDIT 2009 (K9) USA (E03)

FRONT BRAKE HOSE (GSF1250SAK7/SAK8/SAK9) GSF1250S BANDIT 2009 (K9) USA (E03)

FRONT BRAKE HOSE (GSF1250SAK7/SAK8/SAK9) GSF1250S BANDIT 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5924018H10
ref: 1

HOSE,FR BRAKE NO.2

€ 99.00

2

5926938G00
ref: 2

CLAMP,FR BRAKE HOSE NO.2,L

€ 10.50

3

5925318H00
ref: 3

CLAMP,FR BRAKE HOSE ASSY

€ 8.00

4

015500616B
ref: 4

BOLT

€ 2.50

5

5944018H10
ref: 5

HOSE,FR BRAKE NO.2,L

€ 67.50

6

5948018H20
ref: 6

HOSE,FR BRAKE NO.1

€ 92.00

7

5949138G00
ref: 7

JOINT,FR BRAKE HOSE

€ 60.50

8

5925118H00
ref: 8

CLAMP,FR BRAKE JOINT HOSE

€ 14.50

9

015500616B
ref: 9

BOLT

€ 2.50

10

5920018H00
ref: 10

HOSE ASSY,FR BRAKE NO.1

€ 118.00

11

5940018H00
ref: 11

HOSE ASSY,FR BRAKE NO.2

€ 114.00

12

0940306324
ref: 12

CLAMP

€ 2.50

13

5176162J70
ref: 13

CLAMP,BRAKE PIPE AXLE NO.2

€ 0.00

14

0940307401
ref: 14

CLAMP

€ 3.00

15

015470612B
ref: 15

BOLT

€ 2.00

16

0916110009
ref: 16

WASHER(10X15X1.5)

€ 2.00

17

0936010062
ref: 17

BOLT UNION

€ 5.00

18

0936010062
ref: 18

BOLT UNION

€ 5.00

19

0936010064
ref: 19

BOLT UNION

€ 5.00

20

0936010064
ref: 20

BOLT UNION

€ 5.00

21

0940316412
ref: 21

CLAMP

€ 4.00

22

015470612B
ref: 22

BOLT

€ 2.00

23

015500610A
ref: 23

BOLT

€ 2.00

24

0940307336
ref: 24

CLAMP

€ 2.50
