OIL COOLER

GSXR600 2003 (K3) USA (E03)

Oil cooler diagram GSXR600 2003 (K3) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

1660035F00
ref: 1-1
16600-35F10

COOLER ASSEMBLY,OIL

€ 502.50

1-2

1660035F10
ref: 1-2

COOLER ASSY,OIL

€ 502.50

0928064003
ref: 2

O RING(D:3.1,ID:63.9)

€ 5.00

0910606099
ref: 3

BOLT(6X16)

€ 2.50

1646135F00
ref: 4

HOSE,OIL COOLER WATER INLET

€ 22.00

1647135F00
ref: 5

HOSE,OIL COOLER WATER OUTLET

€ 22.50

0940222511
ref: 6

CLAMP

€ 6.00

1651034E00
ref: 7
16510-07J00

FILTER ASSEMBLY,ENGINE OIL

€ 12.50

0940406434
ref: 8

CLAMP(L:80 T:1.0)

€ 3.00
