TRAVEL TRUNK (MODEL J)

GV1400GC CAVALCADE 1988 (J) USA (E03)

Travel trunk (model j) diagram GV1400GC CAVALCADE 1988 (J) USA (E03)

TRAVEL TRUNK (MODEL J) GV1400GC CAVALCADE 1988 (J) USA (E03)

TRAVEL TRUNK (MODEL J) GV1400GC CAVALCADE 1988 (J) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

9310024A7020H
ref: 1-1

TRUNK ASSEMBLY,TRAVEL

€ 1,650.50

1-2

9310024A7038G
ref: 1-2

TRUNK ASSEMBLY,TRAVEL

€ 0.00

2-1

6879024A409VJ
ref: 2-1

TAPE SET,TRAVEL TRUNK

€ 0.00

2-2

6879024A409VK
ref: 2-2

TAPE SET,TRAVEL TRUNK

€ 0.00

3-1

6881024A109VJ
ref: 3-1

TAPE SET,TRUNK LID STRIPE

€ 0.00

3-2

6881024A109VK
ref: 3-2

TAPE SET,TRUNK LID STRIPE

€ 0.00

4-1

9312024A0020H
ref: 4-1

LID,TRAVEL TRUNK

€ 527.00

4-2

9312024A0038G
ref: 4-2

LID,TRAVEL TRUNK

€ 527.00

5

9311524A00
ref: 5

SEAL,TRAVEL TRUNK LID

€ 18.50

6

9314024A01
ref: 6

MIRROR,TRAVEL TRUNK

€ 110.00

7

9313024A01
ref: 7

HINGE,TRAVEL TRUNK

€ 19.50

8

9331624A02
ref: 8

PLATE,TRUNK LID LOCK

€ 15.00

9-1

0831311045
ref: 9-1

NUT

€ 0.00

9-2

0831616055
ref: 9-2

NUT ,5MM

€ 2.00

10

0214205085
ref: 10
02142-0508A

SCREW

€ 2.00

11

9331024A01KEY
ref: 11
93300-24820

LOCK ASSY, SIDE BAG

€ 96.50

12

0110706257
ref: 12
01500-06257

BOLT

€ 2.00

13

0916006105
ref: 13

WASHER

€ 0.00

14

0918006055
ref: 14

SPACER(6.3X9.3X16.5)

€ 4.00

15

0932009030
ref: 15

CUSHION

€ 0.00

16

9541524A00
ref: 16
95415-24A10

SEAT,TRAVEL TRUNK BODY

€ 20.00

17

0930920001
ref: 17

GROMMET

€ 0.00

18

9311624A10
ref: 18

COVER, AIR HOSE

€ 10.00

19

0354104105
ref: 19
03541-0410A

SCREW

€ 1.50

20

0930924001
ref: 20

GROMMET

€ 0.00

21

4542524A00
ref: 21

GROMMET

€ 0.00

22

4542624A00
ref: 22

GROMMET

€ 0.00

23

6828524A00
ref: 23

EMBLEM,TRAVEL TRUNK,UPPER

€ 21.00

24

6828624A00
ref: 24

EMBLEM,TRAVEL TRUNK,LOWER

€ 45.50

25

0213203165
ref: 25

SCREW

€ 1.50

26

0832221035
ref: 26

WASHER

€ 1.50

27

0916203002
ref: 27
09162-03001

WASHER

€ 1.50

28

0831311035
ref: 28

NUT

€ 0.00

29

4542924A10
ref: 29

SEAL

€ 0.00

30

9341024A01
ref: 30

LUGGAGE BAG,TRAVEL TRUNK

€ 115.00

31

6861324A20
ref: 31

LABEL (WARNING TRAVEL T

€ 0.00

32

6861924A00
ref: 32

LABEL, WARNING

€ 0.00
