ELECTRICAL (MODEL S)

JR50 1992 (N) USA (E03)

Electrical (model s) diagram JR50 1992 (N) USA (E03)

prices are in EUR

ref

part #

description

quantity

3341035340
ref: 1

UNIT & COIL ASSY,IGNITION

€ 190.50

0211206207
ref: 2

SCREW

€ 2.00

5862604410
ref: 3

CLIP

€ 0.00

3351035411
ref: 4

CAP ASSY,SPARK PLUG

€ 20.00

3354169010
ref: 5

SEAL,SPARK PLUG

€ 5.00

3354238B00
ref: 6

SEAL,HIGH TENSION CORD

€ 4.50

3782014X50
ref: 7

SWITCH ASSY,ENGINE STOP

€ 24.50

3723846400
ref: 8
37238-46401

LABEL (ENGINE STOP)

€ 0.00

0940406429
ref: 9

CLAMP(L:45)

€ 2.50

0940712402
ref: 10

CLAMP(L:120)

€ 3.00

0940718301
ref: 11

CLAMP

€ 6.00

all assemblies
