FRONT FENDER

JR50 2003 (K3) USA (E03)

Front fender diagram JR50 2003 (K3) USA (E03)

prices are in EUR

ref

part #

description

quantity

6815109A00NN3
ref: 1A

EMBLEM,S

€ 9.50

1-1

5311109AA025Y
ref: 1-1

FENDER,FR

€ 22.00

1-2

5311109AA0YR1
ref: 1-2
53111-09AA0-YU1

FENDER, FRONT (YELLOW)

€ 31.50

1-3

5311109AA0YU1
ref: 1-3

FENDER,FR

€ 31.50

0911606170
ref: 2

BOLT(6X16)

€ 3.00

0916906073
ref: 3

WASHER

€ 4.00

4-1

9491109AA030H
ref: 4-1

PLATE,NUMBER FR

€ 16.50

4-2

9491109AA0YR1
ref: 4-2

PLATE, FRONT NUMBER (YELLOW)

€ 15.50

4-3

9491109AA0YU1
ref: 4-3

PLATE,NUMBER FR

€ 15.50

4-4

9491109AA030H
ref: 4-4

PLATE,NUMBER FR

€ 16.50

09409063145PK
ref: 5

CLIP(BLACK)

€ 3.50

6-1

6872109A00GY8
ref: 6-1

EMBLEM,SUZUKI

€ 7.50

6-2

6872109A008YM
ref: 6-2

EMBLEM,SUZUKI

€ 10.00
