REAR SWINGING ARM
JR50R 1983 (D) USA (E03)
Rear swinging arm diagram JR50R 1983 (D) USA (E03)
REAR SWINGING ARM JR50R 1983 (D) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
610000442008C
ref: 1
SWING ARM ASSEMBLY,REAR
€ 68.50
2
0931910014
ref: 2
BUSH
€ 11.50
3
6121113200
ref: 3
SHAFT,REAR SWING ARM
€ 8.50
4
0932020002
ref: 4
CUSHION
€ 5.00
5
0832121108
ref: 5
08321-01107
LOCK WASHER
€ 2.00
6
0831011108
ref: 6
08310-00107
NUT
€ 2.50
7
6122304420
ref: 7
CAP,RR SHOCK ABSORBER BOSS
€ 42.50
8
6210004410
ref: 8
ABSORBER ASSY,RR SHOCK
€ 178.00
9
0110710358
ref: 9
01500-1035B
BOLT,M10X1.25X
€ 2.50
10
0832221108
ref: 10
08322-01107
WASHER
€ 2.50
11
0110706128
ref: 11
01500-06127
BOLT
€ 2.00
12
0832121068
ref: 12
08321-01067
LOCK WASHER
€ 2.50
13
0916006004
ref: 13
09160-06134
WASHER (6.5X24X1.6)
€ 1.50
14
6131004410
ref: 14
CASE,CHAIN
€ 25.00
15
0110706128
ref: 15
01500-06127
BOLT
€ 2.00
16
0832121068
ref: 16
08321-01067
LOCK WASHER
€ 2.50
