FRAME - FRAME LH COVER

MT50 TRAILHOPPER 1973 (K) USA (E03)

Frame - frame lh cover diagram MT50 TRAILHOPPER 1973 (K) USA (E03)

prices are in EUR

ref

part #

description

quantity

4110027001019
ref: 1

NO PRODUCT DESCRIPTION AVAILABLE

€ 0.00

4155027000
ref: 2

NO PRODUCT DESCRIPTION AVAILABLE

€ 0.00

0111206128
ref: 3
01500-06127

BOLT

€ 2.00

0832121068
ref: 4
08321-01067

LOCK WASHER

€ 2.50

0832221068
ref: 5
08322-01067

WASHER

€ 2.00

6-1

4721027000189
ref: 6-1
47210-27000-019

47210-27000-019

€ 0.00

6-2

4721027600546
ref: 6-2

NO PRODUCT DESCRIPTION AVAILABLE

€ 19.50

6-3

4721027000709
ref: 6-3
47210-27000-019

47210-27000-05E

€ 0.00

0111206408
ref: 7
01500-0640B

BOLT

€ 2.00

0111206708
ref: 8
09100-06062

BOLT(6X70)

€ 3.50

0918006024
ref: 9
09180-06298

SPACER (6.8X10X27.4)

€ 3.00

0918006037
ref: 10

SPACER

€ 6.00

0832121068
ref: 11
08321-01067

LOCK WASHER

€ 2.50

0980000132
ref: 12
09800-21026

TOOL ASSY

€ 9.00

0993020111
ref: 13

WRENCH, CONTACT POINT

€ 22.50

0981800001
ref: 14

CONTACT POINT FILE

€ 1.50

FRAME - FRAME LH COVER
