CARBURETOR

ref

part #

description

quantity

0

1320038010
ref: 0
13200-38011

CARBURETOR ASSEMBLY

€ 187.00

1

1368116601
ref: 1

CAP

€ 7.00

2

1357725710
ref: 2

ADJUSTER,CABLE

€ 1.50

3

1366116600
ref: 3

NUT

€ 5.00

4

1357334011
ref: 4

SPRING

€ 2.00

5

1339434010
ref: 5

CLIP

€ 8.00

6

1339834010
ref: 6
13581-40200

CONNECTOR

€ 7.00

7

0211103067
ref: 7
02112-0306B

SCREW

€ 2.00

8

1356134612
ref: 8

NO PRODUCT DESCRIPTION AVAILABLE

€ 19.00

9

1338338010
ref: 9

NEEDLE JET

€ 7.00

10

1339410010
ref: 10

CLIP

€ 4.50

11

1326734011
ref: 11

ADJUSTER

€ 5.50

12

1326831011
ref: 12

SPRING,THROTTLE STOP

€ 7.50

13

1329430010
ref: 13
13278-02340

O-RING

€ 1.50

14

1329134010
ref: 14

COVER

€ 5.50

15

1326931011
ref: 15

SCREW,PILOT AIR

€ 12.50

16

1329533010
ref: 16

O RING

€ 4.50

17

1326801010
ref: 17

SPRING

€ 3.50

18

0949400144
ref: 18

JET,NEEDLE

€ 0.00

19

1338203110
ref: 19

WASHER

€ 2.50

20

0949129002
ref: 20

JET,MAIN(145)

€ 8.00

21

0949230003
ref: 21
09492-30006

JET

€ 8.50

22

1339258600
ref: 22

GASKET,VALVE SEAT (NAS)

€ 2.00

23

1337018111
ref: 23

VALVE ASSY,NEEDLE

€ 51.50

24

1325401010
ref: 24

PIN,FLOAT

€ 3.00

25

1325330010
ref: 25

ARM,FLOAT

€ 0.00

26

1325218620
ref: 26

FLOAT

€ 27.50

27-1

1325118010
ref: 27-1
13251-33110

GASKET,FLOAT CHAMBER (MCA)

€ 10.50

27-2

1325133110
ref: 27-2

GASKET,FLOAT CAHMBER (NAS)

€ 10.50

28

1324905010
ref: 28

GASKET,DRAIN,PLUG (NAS)

€ 1.50

29

1324705010
ref: 29

PLUG

€ 6.00

30

0211104168
ref: 30
02112-0416A

SCREW

€ 1.00

31

0832121041
ref: 31

LOCK WASHER

€ 2.00

32

1329597700
ref: 32

O-RING

€ 5.00

33-1

0949128002
ref: 33-1
09491-28009

JET

€ 6.50

33-2

0949130003
ref: 33-2
09491-30017

JET

€ 12.00

33-3

0949132002
ref: 33-3

JET,MAIN(160)

€ 6.50

33-4

0949134002
ref: 33-4

JET,MAIN(170)

€ 7.00

all assemblies
