CRANKSHAFT (MODEL J)

RM80 1986 (G) USA (E03)

Crankshaft (model j) diagram RM80 1986 (G) USA (E03)

CRANKSHAFT (MODEL J) RM80 1986 (G) USA (E03)

CRANKSHAFT (MODEL J) RM80 1986 (G) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

1211002B210F0
ref: 1-1
12110-02B22-0F0

PISTON

€ 622.00

1-2

1211002B21050
ref: 1-2
12103-02811-050

PISTON

€ 101.50

1-3

1211002B21100
ref: 1-3
12103-02811-100

PISTON

€ 107.00

2-1

1214102B50
ref: 2-1
12141-02B70

RING,PISTON (STD)

€ 27.00

2-2

1214102B50050
ref: 2-2

RING,PISTON (OS:0.5)

€ 10.00

2-3

1214102B50100
ref: 2-3

RING,PISTON

€ 10.50

3

1215120910
ref: 3

PIN,PISTON

€ 10.00

4

0938114001
ref: 4

RING,SNAP 14MM

€ 1.50

5

0926314016
ref: 5

BEARING(14X18X16)

€ 10.50

6

1220002B10
ref: 6

CRANKSHAFT ASSY

€ 393.50

7

1216102B10
ref: 7

ROD,CONNECTING

€ 49.50

8

0916018023
ref: 8

WASHER (18X23.5X1.5)

€ 3.50

9

1221120901
ref: 9
12211-02B42

PIN,CRANK

€ 24.00

10

0926318026
ref: 10
09263-18026-0C0

BEARING

€ 30.00

11

1222102B10
ref: 11

CRANKSHAFT,R

€ 128.50

12

1226102B10
ref: 12

CRANKSHAFT,L

€ 128.50

13

0926220082
ref: 13

BEARING(20X52X15)

€ 18.00

14

0926220083
ref: 14

BEARING(20X47X14)

€ 28.00

15

0928932003
ref: 15

SEAL,OIL(32X44X8)

€ 11.50

16

0928318004
ref: 16

SEAL,OIL(18X30X8)

€ 5.00

17

1235902B00
ref: 17

SPACER,PRIMARY DRIVE GEAR

€ 16.00

18

0928020004
ref: 18

O RING(D:2.4,ID:19.8)

€ 3.00

19

2111102B01
ref: 19

GEAR,PRIMARY DRIVE

€ 37.00

20

0914016024
ref: 20

NUT

€ 3.50

21

0916416002
ref: 21

WASHER

€ 3.00

22-1

1210102871
ref: 22-1
12101-02872

PISTON SET (STD)

€ 115.00

22-2

1210102871050
ref: 22-2
12101-02872-050

PISTON SET (OS:0.5)

€ 59.00
