FRONT FORK

ref

part #

description

quantity

0-1

5110032110
ref: 0-1

DAMPER SET

€ 0.00

0-2

5110032112
ref: 0-2

DAMPER SET

€ 0.00

1-1

5113032110
ref: 1-1

TUBE,OUTER,RIGHT

€ 0.00

1-2

5113032111
ref: 1-2

TUBE,OUTER,RIGHT

€ 0.00

2-1

5114032110
ref: 2-1

TUBE,OUTER,LEFT

€ 49.00

2-2

5114032111
ref: 2-2

TUBE,OUTER,LEFT

€ 49.00

3

5115334010
ref: 3

SEAL,OIL

€ 15.00

4

5115632110
ref: 4

CIRCLIP,FORK OIL SEAL

€ 6.00

5

5115832110
ref: 5

RING,FORK BACK UP

€ 3.00

6

5111132110
ref: 6

TUBE,FORK,INNER

€ 47.00

7-1

5114632110
ref: 7-1

CYLINDER,FRONT FORK

€ 0.00

7-2

5114632112
ref: 7-2

CYLINDER,FRONT FORK

€ 0.00

8-1

5119532110
ref: 8-1

PIECE,OIL LOCK

€ 0.00

8-2

5119532111
ref: 8-2
51195-38010

PIECE,OIL LOCK

€ 16.00

9

5114816510
ref: 9

GASKET (NAS)

€ 2.00

10

5114716510
ref: 10

BOLT,FORK CYLINDER(10X25)

€ 3.50

11-1

0142108458
ref: 11-1

STUD BOLT

€ 2.50

11-2

5113731010
ref: 11-2
09108-08142

BOLT,STUD

€ 2.00

12

5113216510
ref: 12

HOLDER,AXLE

€ 11.50

13-1

5113916511
ref: 13-1

NO PRODUCT DESCRIPTION AVAILABLE

€ 1.50

13-2

0832221088
ref: 13-2
08322-01087

WASHER

€ 2.00

14

0914008005
ref: 14
09140-08017

NUT (8MM)

€ 1.50

15

5135132110
ref: 15

CAP,FORK INNER TUBE

€ 13.50

16

5118118510
ref: 16

O-RING,FORK FITTING BOLT

€ 4.50

17

0211104087
ref: 17
02112-04087

SCREW

€ 1.50

18

5118303010
ref: 18

GASKET,DRAIN,PLUG (NAS)

€ 3.00

19-1

5117132110
ref: 19-1

SPRING

€ 10.00

19-2

5117132112
ref: 19-2

SPRING

€ 0.00

20-1

5117216510
ref: 20-1

GUIDE,FRONT FORK SPRING

€ 0.00

20-2

5117234110
ref: 20-2

SEAT,FRONT FORK SPRING

€ 7.50

21-1

5111816510
ref: 21-1

NO PRODUCT DESCRIPTION AVAILABLE

€ 1.50

21-2

5111816511
ref: 21-2

SNAP RING

€ 1.50

22-1

5111216510
ref: 22-1

PISTON L

€ 4.50

22-2

5111216511
ref: 22-2

PISTON M

€ 4.50

23

0832121088
ref: 23
08321-01087

LOCK WASHER

€ 2.00

24

5131132110
ref: 24

HEAD,STEERING STEM

€ 35.50

25-1

5145128310
ref: 25-1

BOLT,FORK INNER TUBE F

€ 2.00

25-2

0910610001
ref: 25-2

BOLT

€ 0.00

26

5135628310
ref: 26

WASHER,STEM HEAD

€ 2.50

27

5135128310
ref: 27

CAP

€ 6.50

28

5621127110
ref: 28

HOLDER,HANDLEBAR

€ 12.50

29

0832121088
ref: 29
08321-01087

LOCK WASHER

€ 2.00

30

0122108358
ref: 30

Bolt

€ 3.50

31

5141132110
ref: 31

STEM,STEERING

€ 46.00

32

5140132110
ref: 32

STEM,STEERING

€ 59.50

33

5161133001
ref: 33
51611-33002

RACE,STEERING,INNER,UPPER

€ 7.00

34

0112210608
ref: 34
01500-1060A

BOLT

€ 3.50

35

0832121108
ref: 35
08321-01107

LOCK WASHER

€ 2.00

36

0831211108
ref: 36
08310-00107

NUT

€ 2.50

37-1

5145115010
ref: 37-1

BOLT,FORK INNER TUBE F

€ 4.00

37-2

0112210508
ref: 37-2
01500-1050A

BOLT 10X50

€ 7.00

38

0832121108
ref: 38
08321-01107

LOCK WASHER

€ 2.00

39

0831211108
ref: 39
08310-00107

NUT

€ 2.50

40

5117332110
ref: 40

SEAL,DUST

€ 13.00

41

5145628310
ref: 41

BOLT

€ 0.00

all assemblies
