CARBURETOR

ref

part #

description

quantity

0-1

1320030112
ref: 0-1

CARBURETOR ASSEMBLY

€ 0.00

0-2

1320030640
ref: 0-2

CARBURETOR ASSEMBLY

€ 0.00

0-3

1320030642
ref: 0-3

CARBURETOR ASSEMBLY

€ 0.00

1

1339216600
ref: 1

GASKET,MAIN JET HOLDER (NAS)

€ 3.00

2

1325411010
ref: 2

PIN,FLOAT

€ 3.00

3

1325316600
ref: 3

ARM,FLOAT

€ 2.00

4

1338330111
ref: 4

NEEDLE JET

€ 8.00

5

1339410010
ref: 5

CLIP

€ 4.50

6-1

0949240004
ref: 6-1

JET,PILOT(40)

€ 17.50

6-2

0949235004
ref: 6-2

JET,PILOT(35)

€ 7.50

7-1

1355130111
ref: 7-1

VALVE,THROTTLE

€ 0.00

7-2

1355130112
ref: 7-2

VALVE,THROTTLE

€ 24.00

8-1

1325116600
ref: 8-1

GASKET,FLOAT CHAMBER (MCA)

€ 2.00

8-2

1325116510
ref: 8-2

GASKET,FLOAT CHAMBER

€ 5.50

8-3

1325130110
ref: 8-3

GASKET,FLOAT CAHMBER (NAS)

€ 8.50

9-1

1325916510
ref: 9-1

PLATE

€ 0.00

9-2

1325930110
ref: 9-2

PLATE

€ 0.00

10

1326716400
ref: 10

ADJUSTER

€ 4.00

11

1326803110
ref: 11

SPRING,THROTTLE SCREW

€ 3.50

12

1366216510
ref: 12

NUT, STOP SCREW

€ 3.50

13-1

1325216600
ref: 13-1

FLOAT

€ 17.50

13-2

1325232010
ref: 13-2

FLOAT

€ 25.50

14

1358116600
ref: 14

PLATE,THROTTLE VALVE

€ 4.00

15

1324916600
ref: 15

GASKET,DRAIN PLUG

€ 0.00

16-1

1324716600
ref: 16-1

SCREW,DRAIN

€ 0.00

16-2

1324730110
ref: 16-2

PLUG

€ 0.00

17-1

1338203110
ref: 17-1

WASHER

€ 2.50

17-2

1333116510
ref: 17-2

RING

€ 1.50

18-1

0949400104
ref: 18-1

JET,NEEDLE

€ 7.50

18-2

0949400137
ref: 18-2

JET,NEEDLE

€ 5.50

19

0211205168
ref: 19
02112-05167

SCREW

€ 2.50

20

0832121058
ref: 20
08321-0105A

LOCK WASHER

€ 2.00

21

1357316601
ref: 21

SPRING

€ 1.50

22

1366116600
ref: 22

NUT

€ 5.00

23

1357703010
ref: 23
13577-48110

ADJUSTER,CABLE

€ 8.00

24

1326801010
ref: 24

SPRING

€ 3.50

25

1326915010
ref: 25

SCREW,PILOT AIR

€ 10.50

26-1

1337016600
ref: 26-1

VALVE ASSY,NEEDLE

€ 45.00

26-2

1337030630
ref: 26-2

VALVE ASSEMBLY,NEEDLE

€ 28.50

27-1

0949146001
ref: 27-1

JET,MAIN(230)

€ 6.50

27-2

0949140004
ref: 27-2
09491-40006

JET

€ 11.50

28-1

1368130100
ref: 28-1
13681-16601

CAP

€ 7.00

28-2

1368116601
ref: 28-2

CAP

€ 7.00

29-1

0949136003
ref: 29-1
09491-36006

JET

€ 15.00

29-2

0949138003
ref: 29-2
09491-38009

JET

€ 10.00

29-3

0949142001
ref: 29-3
09491-42005

JET,MAIN (210)

€ 11.00

29-4

0949144001
ref: 29-4
09491-44007

JET,MAIN (220)

€ 9.50

29-5

0949148001
ref: 29-5
09491-48003

JET

€ 13.00

29-6

0949150003
ref: 29-6
09491-50008

JET

€ 12.50

29-7

0949152001
ref: 29-7
09491-52006

JET

€ 7.50

29-8

0949154001
ref: 29-8
09491-54002

JET

€ 11.50

30

1368616600
ref: 30
09351-35653-600

HOSE

€ 5.50

31

0934403016
ref: 31
09351-35653-600

HOSE

€ 5.50

all assemblies
