HANDLEBAR

VL800T BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

Handlebar diagram VL800T BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

HANDLEBAR VL800T BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

HANDLEBAR VL800T BOULEVARD C50 2007 (K7) USA CALIFORNIA (E03 E33)

prices are in EUR

ref

part #

description

quantity

1-1

5611141F00
ref: 1-1

HANDLEBAR

€ 255.50

1-2

5611141F10
ref: 1-2

HANDLEBAR

€ 255.50

1-3

5611141F30
ref: 1-3

HANDLEBAR

€ 167.50

2

5620010890
ref: 2
56200-10891

BALANCER SET,H

€ 38.50

3

0912706017
ref: 3

SCREW(6X127)

€ 2.50

4

5627226D01
ref: 4

EXPANDER,HANDLE BALANCER NO.2

€ 5.00

5

5627617D00
ref: 5

SPACER,EXPANDER

€ 2.50

6

0916006131
ref: 6

WASHER(6.5X16X4)

€ 2.50

7

5627210G10
ref: 7

EXPANDER,HANDLE BALANCER

€ 3.00

8

5627310G10
ref: 8

NUT,HANDLE BALANCER

€ 6.50

9

5650041F00
ref: 9
56500-41F01

MIRROR ASSY,RE

€ 60.50

10

5660041F00
ref: 10
56600-41F01

MIRROR ASSY,RE

€ 60.50

11-1

5820041F20
ref: 11-1

CABLE ASSY,CLUTCH

€ 57.50

11-2

5820041F30
ref: 11-2

CABLE ASSY,CLUTCH

€ 39.00

12-1

5830041FA0
ref: 12-1

CABLE ASSY,THROTTLE NO.1

€ 63.00

12-2

5830041F40
ref: 12-2

CABLE ASSY,THROTTLE NO.1

€ 52.00

12-3

5830043H00
ref: 12-3

CABLE ASSY,THROTTLE NO.1

€ 29.00

13-1

5830041FB0
ref: 13-1

CABLE ASSY,THROTTLE NO.2

€ 67.50

13-2

5830041F50
ref: 13-2

CABLE ASSY,THROTTLE NO.2

€ 43.50

13-3

5830043H10
ref: 13-3

CABLE ASSY,THROTTLE NO.2

€ 27.50

14

5862641F01
ref: 14

GUIDE,THROTTLE CABLE

€ 4.50

15

0913905033
ref: 15

SCREW(5X10)

€ 2.00

16

015500616A
ref: 16

BOLT

€ 2.50

17

5862041F00
ref: 17

GUIDE,CABLE

€ 14.50

18

015500612A
ref: 18

BOLT

€ 2.50

19-1

0940719401
ref: 19-1

CLAMP(L:190)

€ 2.00

19-2

0940725401
ref: 19-2

CLAMP(L:235)

€ 4.00

19-3

0940730401
ref: 19-3

CLAMP(L:300)

€ 4.50

20-1

0940800033
ref: 20-1

CLAMP

€ 2.50

20-2

0940800244
ref: 20-2

CLIP

€ 2.00
