TURN SIGNAL LAMP

VS700GLP INTRUDER 1987 (H) USA (E03)

Turn signal lamp diagram VS700GLP INTRUDER 1987 (H) USA (E03)

TURN SIGNAL LAMP VS700GLP INTRUDER 1987 (H) USA (E03)

TURN SIGNAL LAMP VS700GLP INTRUDER 1987 (H) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3560138A32
ref: 1
35601-38A32-999

LAMP ASSEMBLY,FRONT TURN SIGNAL

€ 135.50

2

3561238A30
ref: 2

LENS

€ 16.50

3

3561338A00
ref: 3

GASKET (NAS)

€ 11.50

4

3562438A00
ref: 4

REFLECTOR

€ 15.00

5

0321104258
ref: 5
03211-0425B

SCREW TAPP.

€ 2.00

6

3562743010
ref: 6

GASKET (NAS)

€ 2.00

7

0947112084
ref: 7

BULB(12V23/8W,TOKAI DENSO)

€ 6.00

8

3562338A01
ref: 8

SCREW

€ 5.50

9

0214206108
ref: 9
02142-06107

SCREW

€ 2.00

10

3567138A00
ref: 10

BRACKET,FRONT TURN SIGNAL

€ 65.50

11

3568138A00
ref: 11

BRACKET,FRONT TURN SIGNAL

€ 62.00

12

0711006167
ref: 12
07130-06167

BOLT

€ 3.00

13

0925005008
ref: 13

CAP(OD:10)

€ 5.00

14

3560338A02
ref: 14
35603-38A02-999

LAMP ASSEMBLY,REAR TURN SIGNAL

€ 105.00

15

3561238A00
ref: 15
35612-38A01

LENS

€ 10.50

16

3561338A00
ref: 16

GASKET (NAS)

€ 11.50

17

3562438A00
ref: 17

REFLECTOR

€ 15.00

18

0321104256
ref: 18
03211-0425B

SCREW ,4X25

€ 2.00

19

3562743010
ref: 19

GASKET (NAS)

€ 2.00

20

0947112006
ref: 20

BULB(12V23W,STANLEY,A4577A)

€ 4.00

21

3562338A01
ref: 21

SCREW

€ 5.50

22

0214206108
ref: 22
02142-06107

SCREW

€ 2.00

23

3861031310
ref: 23
38610-31X50

RELAY ASSEMBLY,TURN SIGNAL

€ 54.50
