FRONT CALIPER
VS700GLP INTRUDER 1989 (K) USA (E03)
Front caliper diagram VS700GLP INTRUDER 1989 (K) USA (E03)
FRONT CALIPER VS700GLP INTRUDER 1989 (K) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
5910038A00
ref:
59100-38A02-999
CALIPER ASSEMBLY,FRONT,RIGHT
€ 595.50
5910038A01
ref:
59100-38A02-999
CALIPER ASSEMBLY,FRONT,RIGHT
€ 595.50
1-1
6910024820
ref: 1-1
69100-24821
PISTON SET
€ 102.00
1-2
6910024821
ref: 1-2
PISTON SET
€ 102.00
2
5513666310
ref: 2
69107-38B00
SEAL,FR CALIPE
€ 8.50
3
6910845000
ref: 3
BOOT,PISTON
€ 10.00
4
6910734200
ref: 4
SEAL,JOINT
€ 12.00
5
5913038B10
ref: 5
59100-38820
PAD
€ 41.50
6
5937133410
ref: 6
SHIM,PAD
€ 15.00
7
5914516700
ref: 7
BOLT,HOUSING
€ 8.00
8
5914316700
ref: 8
SPRING
€ 7.50
9
6914145000
ref: 9
PIN,PAD
€ 6.50
10
6914245000
ref: 10
CLIP,PAD PIN
€ 4.50
11
5915138B00
ref: 11
59151-38B01
COVER,CALIPER
€ 58.00
12
5915224A00
ref: 12
CAP,CALIPER
€ 23.50
13
5912118410
ref: 13
BLEEDER
€ 8.00
14
5912218410
ref: 14
55156-66310
CAP,BREATHER
€ 6.00
15
5915338B00
ref: 15
59153-38B10
SCREW,CALIPER COVER (4X
€ 7.50
16
0910610038
ref: 16
BOLT(10X33)
€ 4.50
17
0925008014
ref: 17
CAP(OD:12)
€ 3.50
