FRAME

DR-Z110 2004 (K4) USA (E03) DRZ110 DR Z110

Frame diagram DR-Z110 2004 (K4) USA (E03) DRZ110 DR Z110

FRAME DR-Z110 2004 (K4) USA (E03) DRZ110 DR Z110

FRAME DR-Z110 2004 (K4) USA (E03) DRZ110 DR Z110

prices are in EUR

ref

part #

description

quantity

600

KK600A0600
ref: 600

BALL-STEEL,3/16

€ 0.00

32160

K321601773466
ref: 32160

FRAME-COMP

€ 534.50

46098

KK46098018
ref: 46098

CAP,STEERING STEM

€ 4.50

92015

K920151222
ref: 92015

NUT,STEERING LOCK,25MM

€ 19.50

92047

KK92047014
ref: 92047

CONE,STEERING STEM BEARING

€ 9.50

92048

KK92048009
ref: 92048

RACE,STEERING STEM BEARING

€ 12.00
