FRONT MASTER CYLINDER

RM-Z250 2014 (L4) USA (E03) RMZ250 RM Z250

Front master cylinder diagram RM-Z250 2014 (L4) USA (E03) RMZ250 RM Z250

prices are in EUR

ref

part #

description

quantity

5960028H00
ref: 1

CYLINDER ASSY,FR MASTER

€ 239.50

5960037810
ref: 2

PISTON & CUP SET

€ 35.50

5966644300
ref: 3

BOOT

€ 6.00

5966714500
ref: 4

DIAPHRAGM

€ 6.50

5966927C01
ref: 5

CAP

€ 10.00

6968949300
ref: 6

SCREW

€ 1.50

5967128H00
ref: 7

HOLDER

€ 22.50

5967506F10
ref: 8

BOLT

€ 2.50

5974836E00
ref: 9

SEPARATOR

€ 5.00

5751728H00
ref: 10

BOLT,MASTER CYLINDER HOLDER

€ 7.00

0936010065
ref: 11

BOLT UNION

€ 5.50

0916110009
ref: 12

WASHER(10X15X1.5)

€ 2.00

5948028H00
ref: 13

HOSE,FR BRAKE

€ 162.50

5926028H20
ref: 14

CLAMP,FR BRAKE HOSE INNER

€ 14.50

5927128H10
ref: 15

CLAMP,FR BRAKE HOSE

€ 6.50

0910306234
ref: 16

BOLT(6X16)

€ 2.50

5715328H01
ref: 17

LEVER,MASTER CYLINDER HOLDER

€ 12.50

5751628H10
ref: 18

COVER,MASTER CYL HOLDER LEVER

€ 6.00
