FRONT MASTER CYLINDER

DL1000 VSTROM 2006 (K6) USA (E03)

Front master cylinder diagram DL1000 VSTROM 2006 (K6) USA (E03)

FRONT MASTER CYLINDER DL1000 VSTROM 2006 (K6) USA (E03)

FRONT MASTER CYLINDER DL1000 VSTROM 2006 (K6) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5960042F00
ref: 1

CYLINDER ASSY,FR MASTER

€ 271.00

2

5960045860
ref: 2

PISTON & CUP SET

€ 44.00

3

5966644300
ref: 3

BOOT

€ 6.00

4

5966749460
ref: 4

5966749460

5

5966841C00
ref: 5

PLATE,DIAPHRAGM

€ 8.00

6

5966910G00
ref: 6

CAP

€ 19.00

7

6968949300
ref: 7

SCREW

€ 1.50

8

5967132F00
ref: 8

HOLDER

€ 17.00

9

5967502FA0
ref: 9

BOLT(6X22)

€ 3.00

10

5966432F00
ref: 10

PROTECTOR

€ 7.50
