TRANSMISSION (MODEL M/N/P)

ref

part #

description

quantity

1-1

2412014D01
ref: 1-1
24120-14D03

SHAFT,COUNTER

€ 117.00

1-2

2412014D03
ref: 1-2

SHAFT,COUNTER(NT:12)

€ 117.00

2

2422114D00
ref: 2
24221-14D01

GEAR,SECOND DRIVE (NT:15)

€ 88.50

3

2423114D00
ref: 3

GEAR,3RD & 4TH DRIVE(NT:18/18)

€ 108.00

4

2425114D00
ref: 4

GEAR,5TH DRIVE(NT:21)

€ 84.50

5

0821122261
ref: 5
09181-22111

WASHER

€ 3.00

6

2426014D00
ref: 6

GEAR COMP,SIXTH DRIVE

€ 72.00

6A

2426114D02
ref: 6A

GEAR,6TH DRIVE(NT:23)

€ 83.00

6B

0930022008
ref: 6B

BUSH(22X26X9)

€ 10.50

6C

0833131226
ref: 6C
08331-3122A

CIRCLIP

€ 2.00

7

0821122281
ref: 7
09181-22139

SHIM

€ 4.00

7A

0821122301
ref: 7A
09181-22167

WASHER,THRUST

€ 3.00

8-1

0938022006
ref: 8-1

CIRCLIP

€ 3.00

8-2

0938022006
ref: 8-2

CIRCLIP

€ 3.00

9

0926220065
ref: 9
09262-20145

BEARING

€ 24.00

10-1

0926217018
ref: 10-1
09262-17027

BEARING

€ 25.00

10-2

0926217027
ref: 10-2

BEARING(17X40X12)

€ 25.00

11-1

2413014D11
ref: 11-1
24130-14D14

SHAFT,DRIVE

€ 179.00

11-2

2413014D13
ref: 11-2
24130-14D14

SHAFT,DRIVE

€ 179.00

12

2431114D00
ref: 12
24311-14D01

GEAR,FIRST DRIVEN (NT:29)

€ 61.50

13

2431214D00
ref: 13

BUSH,1ST DRIVEN GEAR

€ 15.00

14

0821117322
ref: 14

WASHER

€ 2.50

15

0821122301
ref: 15
09181-22167

WASHER,THRUST

€ 3.00

16

0938022006
ref: 16

CIRCLIP

€ 3.00

17

2432014D00
ref: 17

GEAR,2ND DRIVEN(NT:26)

€ 87.50

18

0821125341
ref: 18
09181-25167

WASHER

€ 3.50

19

0938025010
ref: 19

CIRCLIP

€ 3.00

20-1

2433114D00
ref: 20-1
24331-14D01

GEAR,THIRD DRIVEN

€ 87.50

20-2

2433114D01
ref: 20-2

GEAR,3RD DRIVEN(NT:24)

€ 87.50

21

0821122281
ref: 21
09181-22139

SHIM

€ 4.00

22

2434114D00
ref: 22

GEAR,4TH DRIVEN(NT:20)

€ 80.50

23

2435114D00
ref: 23
24351-14D01

GEAR,FIFTH DRIVEN (NT:20)

€ 95.00

24-1

2436114D00
ref: 24-1
24361-14D01

GEAR,SIXTH DRIVEN

€ 95.50

24-2

2436114D01
ref: 24-2

GEAR,6TH DRIVEN(NT:19)

€ 95.50

25

0926717003
ref: 25

BEARING(17X40X17.5)

€ 57.00

26

0926222024
ref: 26

BEARING(22X56X16)

€ 40.00

27

0928322025
ref: 27

SEAL,OIL(22X34X7)

€ 12.50

28

2475114D00
ref: 28

RETAINER,DRIVE SHAFT OIL SEAL

€ 8.00

29

0110706126
ref: 29
01500-0612A

BOLT

€ 2.00

30

2626114D10
ref: 30

GEAR,KICK STARTER IDLE(NT:27)

€ 58.50

31

2626214D00
ref: 31

BUSH,KICK STARTER IDLE GEAR

€ 11.00

32

2626414D00
ref: 32

RETAINER,KICK IDLE GEAR

€ 10.00

33

0918006229
ref: 33
09180-06314

SPACER (6.5X12X21)

€ 2.50

34

0212206167
ref: 34

SCREW

€ 2.00

35

0212206356
ref: 35
02122-0635B

SCREW

€ 2.00

36

2751114310
ref: 36
27511-37F00

SPROCKET,ENGINE

€ 23.50

37

0938022012
ref: 37

CIRCLIP

€ 3.50

38

2760013A60112
ref: 38
27600-06C20-114

CHAIN ASSEMBLY,DRIVE RK520

€ 125.00

all assemblies
