MUFFLER

ref

part #

description

quantity

1

1410047300
ref: 1

PIPE,EXHAUST,CENTER

€ 306.00

2

1418103310
ref: 2

GASKET,EXHAUST PIPE (NAS)

€ 7.00

3

0110708358
ref: 3

BOLT

€ 3.50

4

0832121088
ref: 4

LOCK WASHER

€ 2.00

5

1477147010
ref: 5

CONNECTOR,MUFFLER

€ 35.00

6

1445934200
ref: 6

CLAMP,MUFFLER CONNECTOR,R

€ 13.00

7

1446934200
ref: 7

CLAMP,MUFFLER CONNECTOR,L

€ 13.00

8

0151708258
ref: 8

BOLT

€ 2.50

9-1

1430147300
ref: 9-1

MUFFLER ASSEMBLY

€ 405.50

9-2

1430147320
ref: 9-2
E17

MUFFLER, RH

€ 0.00

10-1

1430247300
ref: 10-1

MUFFLER ASSEMBLY

€ 385.00

10-2

1430247320
ref: 10-2
E17

MUFFLER, LH

€ 0.00

11

1470134500
ref: 11

COVER,MUFFLER,RIGHT

€ 37.50

12

1470234500
ref: 12

COVER,MUFFLER,LEFT

€ 44.50

13

1478534200
ref: 13

CLAMP,MUFFLER COVER

€ 8.00

14

0211205168
ref: 14

SCREW

€ 2.50

15

0211206128
ref: 15

SCREW 6X12

€ 2.00

16

0832121068
ref: 16

LOCK WASHER

€ 2.50

17

0832221068
ref: 17

WASHER

€ 2.00

18

0916806005
ref: 18

GASKET 6.2X12X1.5 (MCA)

€ 2.00

all assemblies
