REAR FENDER
GS500EU 1998 (W) (E04 E22 E39)
Rear fender diagram GS500EU 1998 (W) (E04 E22 E39)
REAR FENDER GS500EU 1998 (W) (E04 E22 E39)
×
prices are in EUR
ref
part #
description
quantity
1
6311101D30
ref: 1
BODY,REAR FENDER
€ 20.50
1
6311101D20
ref: 1
E18,E22,E25
BODY,RR FENDER
€ 108.00
1
6311101D40
ref: 1
E39
BODY, REAR FENDER
€ 87.00
2
0155006123
ref: 2
MODEL V
BOLT
€ 2.50
2
0911106066
ref: 2
MODEL W/X
BOLT(6X16)
€ 2.50
3
0155006163
ref: 3
BOLT
€ 2.50
4
0916906037
ref: 4
WASHER
€ 6.50
5
6321001D10
ref: 5
BRACE,RR FENDER,R
€ 73.50
6
6322001D10
ref: 6
BRACE,RR FENDER,L
€ 73.50
7
0155008123
ref: 7
BOLT
€ 3.50
8
0155008203
ref: 8
BOLT
€ 3.00
9
4742501D00
ref: 9
PLATE,TOOL HOLDER
€ 4.50
10
0980021017
ref: 10
TOOL ASSY
€ 59.00
11
0982200005
ref: 11
CLAMP
€ 22.00
12
0946200046
ref: 12
BAND
€ 4.50
13
9572001D00
ref: 13
HOLDER,HELMET
€ 7.00
14
0157006203
ref: 14
MODEL V/W
BOLT
€ 2.50
14
0155006163
ref: 14
MODEL X
BOLT
€ 2.50
15
6341142A00
ref: 15
GUARD,RR UNIT MUD
€ 3.50
16
0916906010
ref: 16
WASHER
€ 3.00
17
0214206163
ref: 17
SCREW
€ 2.50
18
6331112C00
ref: 18
E25
EXTENSION,RR FENDER
€ 19.50
19
0214206163
ref: 19
E25
SCREW
€ 2.50
20
0916006019
ref: 20
E25
WASHER(6.5X16X1.2)
€ 1.50
21
0831921068
ref: 21
E25
NUT 6MM
€ 2.00
22
6331101D40
ref: 22
E18,E22,E39
EXTENSION,RR FENDER
€ 18.00
23
6333148B12
ref: 23
E18,E22,E39
MUDGUARD,RR FENDER
€ 31.00
24
0214206163
ref: 24
E18,E22,E39
SCREW
€ 2.50
25
0916006019
ref: 25
E18,E22,E39
WASHER(6.5X16X1.2)
€ 1.50
26
0831921068
ref: 26
E18,E22,E39
NUT 6MM
€ 2.00
27
6311506C00
ref: 27
TAPE,RR FENDER
€ 7.00
28
6831933E00
ref: 28
LABEL (WARNING SAFETY),E
€ 8.00
28
6831933E20
ref: 28
E18,E22,E34,E39
LABEL,WARNING
€ 8.00
28
6831933E30
ref: 28
E4,E18,E34
LABEL,WARNING
€ 8.50
28
6831933E40
ref: 28
E18,E34
LABEL,WARNING
€ 8.00
28
6831933E70
ref: 28
E25,E34
LABEL,WARNING
€ 5.50
28
6831933E50
ref: 28
E34
LABEL,WARNING
€ 8.00
28
6831933E80
ref: 28
P37
LABEL, WARNING SAFETY (DOTUGUESE)
€ 4.00
29
6862317D00
ref: 29
E2
LABEL,CAUTION
€ 4.00
30
6833201D00
ref: 30
MODEL V
LABEL,TIRE AIR PRESSURE
€ 4.50
30
6833201D10
ref: 30
MODEL V E4
LABEL, TIRE AIR PRESSURE
€ 0.00
30
6833201D30
ref: 30
MODEL W
LABEL, TIRE INFORMATION
€ 7.00
31
8693273060
ref: 31
E24
LABEL,FUEL CAUTION
€ 4.00
32
9901101D5828B
ref: 32
MODEL V
MANUAL, OWNER'S
€ 19.00
32
9901101D58042
ref: 32
MODEL V, E18,E22,E25
O.M. GS500E V
€ 21.00
32
9901101D5928B
ref: 32
MODEL W
MANUAL, OWNER'S
€ 15.00
32
9901101D59042
ref: 32
MODEL W, E18,E22,E25
MANUAL, OWNER'S
€ 21.00
32
9901101D6028B
ref: 32
MODEL X
MANUAL, OWNER'S
€ 0.00
32
9901101D60042
ref: 32
MODEL X, E18,E22,E25
MANUAL, OWNER'S
€ 6.00
32
9901101D60057
ref: 32
MODEL X P37, DRAWING
MANUAL, OWNER'S
€ 0.00
